Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Specifications
Brand Name :
XIANDA
Model Number :
CNC-2500
Certification :
CE
Place of Origin :
FUJIAN,CHINA
MOQ :
1
Price :
USD25000-36500
Payment Terms :
T/T
Supply Ability :
1000 SETS /YEAR
Delivery Time :
15-20 Days after receiving 30% deposit
Packaging Details :
Fixed with steel wire and plastic film inside, moisture-proof and shockproof.
Product Name :
Diamond Wire Saw Machine
Brand :
Custom / OEM & ODM Available
Type :
Automatic CNC Wire Saw Cutter
Usage :
Natural Stone Quarry & Processing
Warranty :
1 Year, Lifetime Technical Support
Cutting Material :
Granite, Marble, Basalt, Limestone, Natural Stone
Drive System :
High Precision Reducer & Servo Motor
Application Scene :
Quarry Mining, Stone Factory Block Cutting, Special Shaped Stone Processing
After-sales Service :
Overseas Installation, On-site Training, Online Guidance
Description
Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Product Overview

High Efficiency Diamond Wire Saw Machine Natural Stone Block Cutting Equipment

Our diamond wire saw is specially engineered for fast and efficient cutting of granite, marble, reinforced concrete, and large construction structures. Manufactured with high-quality diamond beads and durable steel wire, our products deliver stable cutting performance, reduced downtime, and longer operational life in demanding working environments.

Suitable Applications
  • Granite Quarry Cutting
  • Marble Block Cutting
  • Reinforced Concrete Cutting
  • Bridge Demolition
  • Underwater Cutting
  • Construction Projects
Diamond Wire Saw for Granite and Reinforced Concrete Cutting
Product Features
High Cutting Efficiency
  • Advanced diamond bead technology provides faster cutting speed and smoother cutting surfaces

Longer Service Life
  • Premium raw materials improve wear resistance and reduce replacement frequency

Stable Performance
  • Excellent flexibility and strong tension resistance minimize wire breakage during operation

OEM & Custom Service
  • Customized specifications available according to your cutting machine and project requirements
Technical Parameters
Parameter Unit CNC-2000 CNC-2500 CNC-3000
Max processing size mm 2000 x 3000 x 1500 2500 x 3000 x 1500 3000 x 3000 x 1500
Trolley size mm 1300 x 2500 1300 x 2500 1300 x 2500
Table bearing weight T 15 15 15
Main motor kw 11 11 11
Wire Speed m/s 20~40 20~40 20~40
Outline dimension mm 6800 x 6300 x 3800 7800 x 6300 x 3800 8800 x 6300 x 3800
Gross weight kg ≈6000 ≈6250 ≈6500
Water consumption m³/h ≈3 ≈3 ≈3
Main Applications
Diamond Wire Saw for Granite and Reinforced Concrete Cutting

Our diamond wire saw machine is widely applied in:

  • Natural stone quarry mining
  • Granite, marble, basalt block cutting
  • Stone block squaring and special shape profiling
  • Large stone slab trimming and shaping
  • Concrete & construction demolition cutting

Ideal for stone quarry plants, stone processing factories and engineering projects worldwide.

FAQ
What materials can your wire saw cut?
Our diamond wire saw is suitable for granite, marble, reinforced concrete, and other hard materials.
Do you support OEM service?
Yes, we provide OEM and customized solutions based on customer requirements.
What is your MOQ?
Please contact us for detailed MOQ information.
How long is the delivery time?
Usually 7-15 working days depending on order quantity.
Do you provide technical support?
Yes, our technical team can provide product selection and application guidance.
Company Profile

Fujian Xianda Machinery Co., Ltd is a leading company for stone cutting machines and tools in China, established in 1985 and covers 20,000m³ area located in Jinjiang Wuli Industrial area. With more than 40 years' experience specializing in developing and producing a series of diamond wire saw machines, column processing machines, bridge cutting machines, carving machines, profiling linear machines, and baluster machines.

We occupy around 80% of the market in China for column processing machines and serve over 52 overseas countries. Since our foundation in 1985, we maintain "Top Technology and Superior Quality" as our standard for all machines and have obtained CE certification, ISO Quality Gold Award, "China Recommend Building Manufacture Enterprise", "3A Enterprise Credit Evaluation", and other recognitions.

Xianda always maintains "Create the highest value of your stone" as our purpose. Your visiting and contacting is always welcomed.

Our Services
  • We provide machine testing videos and conduct strict inspections and testing for every machine before shipping
  • After-sales service available 24 hours online
  • We provide staff training to continuously improve overall service quality
  • We are responsible for receiving and processing customer complaints regarding product and service quality
  • Professional technical personnel guide machine installation, commissioning, and operator training
