Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Specifications
Type :
diamond wire saw
Application :
Cutting,Marble Quarrying
Material :
Diamond,steel,Diamond wire saw,rubber/Spring
Usage :
Marble Quarrying,Rock cutting,Stone Carving,diamond wire saw
Product name :
11.5mm fast cutting rope quarry diamond wire saw,Small diameter Diamond wire saw for stone cutting,Diamond saw ropes
Advantage :
High Efficiency Long Life Time,High working efficiency,high quality,Fast Cutting,15 years experience
Beads type :
Sintered
Diameter :
11.5mm
Business type :
Manufacturer,Manufacturer and Trading
Brand Name :
Xianda Machinery
Model Number :
MQR115
Place of Origin :
Jinjiang, Fujian, China
MOQ :
1
Price :
To Be Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, ,
Supply Ability :
1000 Sets/Year
Packaging Details :
50cm*50cm*30cm
Description
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
Product Attributes
Attribute Value
Type diamond wire saw
Application Cutting, Marble Quarrying
Material Diamond, steel, Diamond wire saw, rubber/Spring
Usage Marble Quarrying, Rock cutting, Stone Carving, diamond wire saw
Product name 11.5mm fast cutting rope quarry diamond wire saw, Small diameter Diamond wire saw for stone cutting, Diamond saw ropes
Advantage High Efficiency Long Life Time, High working efficiency, high quality, Fast Cutting, 15 years experience
Beads type Sintered
Diameter 11.5mm
Business type Manufacturer, Manufacturer and Trading
Diamond Wire Saw For Marble Quarrying Tools To Cutting Stone 11.5mm
Basic Information
Model NO.: Diamond Wire Saw For Marble Quarrying
Service: ODM, OEM, Customized
Beads Number: 40 Beads Per Meter
Business Type: Manufacturer
Keywords: Marble /Quarring/Stone/Concrete Cutting Diamond Wire
Grade: a-Grade
Usage: Used on Electric Wire Saw Machine
Shipping: by Air, by Sea, by Express(DHL,FedEx,EMS)
Beads Type: Sintered, Electroplated, Brazed
Transport Package: Sealed and Waterproof Plastic Box Packaging
Specification: D11.5mm
Trademark: UNIQUE
Origin: China
Production Capacity: 1000meters/Day
Diamond Wire Saw Features
  • The diamond wire quarrying technique can highly improve the quarrying efficiency, reduce the waste of mining resource
  • It can exploit large dimension blocks. At the same time, it can be operated safely and it is good for environment protection
  • Independently developed the special rubber and vulcanized technique to ensure that the diamond wires can work in all sorts of bad environment
  • The rubber and cable sticking together tightly makes good bonding, and this can be more strikes during the work
  • The vulcanised rubber easily withstands increases in temperature caused by badly controlled water spraying, which often happens in a quarry
  • Strong flexibility can reduce the cut-in-one-side problem, and protect cable well when it used for small curvature radius (beginning and end of quarry cuts)
Technical Specifications
Specification Reinforcement Beads number Cutting material Line speed Cutting speed Wire life
Φ11.5mm Rubber+Spring 40/m Hard marble 20-30m/s 8-12 m²/h 30-40m²/m
Φ11.5mm Rubber+Spring 40/m Middle hard marble 20-35m/s 12-15 m²/h 40-50m²/m
Φ11.5mm Rubber+Spring 40/m Soft marble 25-35m/s 15-20 m²/h 50-70m²/m
Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads Marble Quarrying Diamond Wire Saw Stone Cutting 11.5mm Sintered Beads
