Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Specifications
Wire Length :
10m
Max processing size :
3500*3500*2100mm
Certification :
API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Wheel diameter :
2200mm
Wire Speed :
0-40m/s
Trolley size :
2000*2500mm
Name :
Diamond Wire Saw Machine
Warranty Time :
One Year
Brand Name :
Xianda Machinery
Model Number :
BWT-3000-15 / BWT-3500-18/21
Place of Origin :
Jinjiang, Fujian, China
MOQ :
1
Price :
To Be Negotiable
Packaging Details :
Plastic Package, Suitable for Sea Transportation
Delivery Time :
1 month
Payment Terms :
L/C， T/T， D/P， ，Paypal ，， Others
Supply Ability :
1000 Sets/Year
Max Processing Size :
3000*2500*1500mm
Wire Diameter :
0.6-1.8mm
Automation :
Automatic
Water Consumption :
6m3/H
Control Type :
CNC
Cutting Length :
20-60m
Diameter :
8.5mm to 11.5mm
Cutting Precision :
High
Spindle :
15KW
Trolley Size :
1400*2500mm
Adjustment Distance :
450mm
Gross Motor :
11kw
Control System :
PLC SYSTEM
Rated Power :
2.2kw
Description
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Key Specifications
Attribute Value
Wire Length 20.6m
Max Processing Size 3500*3500*2100mm
Certification API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Wheel Diameter 2200mm
Wire Speed 0-40m/s
Control Type CNC
Cutting Precision High
Warranty One Year
Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting Stone Diamond Wire Saw Machine For Block Squaring And Slabs Cutting
Product Overview

The Diamond Wire Saw Machine is designed for cutting marble, granite, reinforced concrete and other hard materials. With its diamond wire saw technology, it offers superior cutting efficiency and precision for stone processing plants and industrial applications.

Technical Specifications
Model Max Processing Size Wheel Diameter Trolley Size Bearing Weight Main Motor Dimensions Weight Water Consumption
BWT-3000-15 3000*3000*1500mm 1600mm 1600*2000mm 20T 11kw 8800*5500*4100mm 7200kg 5m³/h
BWT-3500-18 3500*3000*1800mm 1900mm 1800*2000mm 35T 11kw 9300*5900*4800mm 9000kg 6m³/h
BWT-3500-21 3500*3500*2100mm 2200mm 2000*2500mm 50T 15kw 9800*6800*5600mm 10700kg 6m³/h
Key Features
  • CNC control system for precise operation
  • High cutting efficiency with wire speed up to 40m/s
  • Robust construction with heavy-duty components
  • Multiple model options for different processing needs
  • International certifications for quality assurance
  • Automatic operation with PLC control system
Applications

This versatile machine is ideal for:

  • Marble and granite block squaring
  • Slab cutting for construction materials
  • Reinforced concrete cutting
  • Industrial stone processing
  • Large-scale quarry operations
Customization Options

We offer customized solutions to meet specific requirements:

  • Multiple model configurations available
  • Custom dimensions and capacities
  • Specialized cutting applications
  • Optional accessories and attachments
Support & Services

Our comprehensive support includes:

  • Technical support via phone and email
  • On-site service when required
  • Detailed operation manuals and videos
  • One-year warranty coverage
  • Spare parts availability
Packaging & Shipping

All machines are securely packaged for international shipping:

  • Solid wooden crates with protective cushioning
  • Clear labeling for easy identification
  • Express delivery (3-5 days) or air freight (5-7 days)
  • Sea transportation suitable packaging
Frequently Asked Questions
What is the brand name of this machine?
The brand name is XIANDA MACHINERY.
What are the available model numbers?
Models include BWT-3000-15, BWT-3500-18, and BWT-3500-21.
Where is the machine manufactured?
Manufactured in Jinjiang, Fujian, China.
What certifications does the machine have?
Certifications include API, CCC, SONCAP, GOST, ISO, CE, SGS, and IAF.
What is the minimum order quantity?
Minimum order quantity is 1 SET.
