Product Description:
Ricardo Diesel Generators are a powerful and reliable source of energy, designed to provide efficient and long-lasting performance. With a compact design and easy-to-use features, these generators are ideal for both residential and commercial use.
- Ricardo Diesel Powered Generators: These generators are equipped with a durable and efficient diesel Ricardo engine, known for its high-quality and reliable performance.
- Generator: This product is a generator, which converts mechanical energy into electrical energy, providing a steady and continuous power supply.
- Power Generator: With a rated voltage of 220/380V, 230V/400V, 240V/415V,127/220V Etc, these generators are capable of providing a reliable power supply for various electrical appliances and equipment.
- High Efficiency: The Ricardo Diesel Generators are designed to provide maximum efficiency, ensuring that every drop of fuel is utilized to its fullest potential, resulting in a longer running time and reduced fuel consumption.
- Compact Design: These generators have a compact and space-saving design, making them suitable for both indoor and outdoor use.
- Easy to Use: The generators are equipped with user-friendly features, making them easy to operate and maintain.
- Options: The Ricardo Diesel Generators come with optional features such as ATS (automatic transfer switch) and a water heater, providing added convenience and functionality.
- TG6120N Controller: This product is equipped with a TG6120N controller, which allows for easy and precise control of the generator's functions.
Features:
- Product Name: Ricardo Diesel Generators
- Engine Brand: Ricardo
- Alternator Insulation: IP21 ~ IP23
- Controller Model: TG6120N
- Rated Voltage: 220/380V, 230V/400V, 240V/415V, 127/220V, Other Voltage Is Optional
- Frequency: 50Hz@1500rpm Or 60Hz@1800rpm
Technical Parameters:
| Technical Parameter for Diesel Generator | Genset Model | TG55R |
| Prime Power | 50kVA/40kW |
| Standby Power | 55kVA/44kW |
| Frequency | 50Hz |
| Rated Voltage | 400V |
| Power Factor | 0.8 |
| Engine Brand | Ricardo |
| Engine Model | ZH4105ZD |
| Alternator Brand | Tecgen |
| Alternator Model | TGI224S-40 |
| Engine General Data | Engine Power(kW) | 50 |
| Cyl / Arrangement | 4L |
| Air Intake way | Turbo |
| Bore×Stroke (mm×mm) | 105x125 |
| Speed Governor | Mechanical |
| Fuel Consumption (g/kw.h)) | 239 |
| Alternator Data | Model | TGI224S-40 |
| Brand | Tecgen Stamford |
| Rate Output | 50kVA/40kW |
| Frequency | 50Hz |
| Altitude | ≤1000 |
| Insulation | Class H |
| Protection Grade | IP 23 |
| Control System | Brand | Tecgen |
| Model | TG6120N |
| Functions | Control with AMF module |
| Static with auto. battery charger |
| Emergency stop push button |
| Alarm |
| Optional brand | Mebay, Smartgen,Deif, Deepsea |
| Starting Voltage | 24V |
Applications:
Ricardo Diesel Generators
When it comes to reliable backup power supply, look no further than Ricardo Diesel Generators. Our brand, Ricardo Generator, offers a range of high-quality diesel gensets equipped with Ricardo engines to meet your emergency power needs. Made in China, our generators are certified with ISO, CE, SASO, and CIQ, ensuring top-notch quality and performance.
Application and Scenarios
Ricardo Backup Generator is suitable for various applications and scenarios, including:
- Industrial and commercial buildings
- Telecommunication and data centers
- Hotels and resorts
- Construction sites
- Agricultural operations
- Outdoor events and concerts
-
Our diesel Ricardo engines can provide reliable power supply in case of power outages or as a primary power source in remote areas. They are also commonly used for peak shaving or grid support to reduce electricity costs.
Product Features
As a leader in the industry, Ricardo Generator offers a wide range of features that make our diesel gensets stand out:
- Reliable Performance: Our generators are equipped with Ricardo engines, known for their reliability and durability.
- Low Fuel Consumption: Our engines are designed to be fuel-efficient, reducing operational costs for our customers.
- Compact Structure: Our generators are designed with a compact structure, making them easy to transport and install in any location.
- Easy Maintenance: Our generators are designed for easy maintenance, reducing downtime and costs for our customers.

Customization:
Ricardo Generator - TGR Series
Customized Service for Your Specific Needs
At Ricardo, we understand that each customer has unique requirements for their power generation needs. That's why we offer a range of customizable options for our TGR series of diesel generators.
Brand Name: Ricardo Generator
Model Number: TGR
Place of Origin: China
Certification: ISO / CE / SASO / CIQ
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Plywood case / Foam and PE film package
Delivery Time: 15 Working Days
Payment Terms: T/T / L/C
Supply Ability: 400 Units Per Month
Alternator Insulation: IP21 ~ IP23
Genset Type: Open / Silent
Rated Voltage: 220/380V, 230V/400V, 240V/415V, 127/220V Etc. Other Voltage Is Optional
Options: ATS / Water Heater
Frequency: 50Hz@1500rpm Or 60Hz@1800rpm
Choose from a variety of specifications and features to create the perfect diesel generator powered by a reliable Ricardo engine. Our customized service allows you to tailor your generator to meet your specific needs, whether it's for backup power at a remote site or prime power for a commercial facility.
With our TGR series, you can trust in the quality and performance of a Ricardo diesel engine generator, backed by our ISO, CE, SASO, and CIQ certifications. Our flexible options and competitive pricing make us a top choice for customized power solutions.
Contact us today to discuss your requirements and let us help you find the best customized solution for your power needs.
