50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled
50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled
50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled
50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled
50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled
50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled
Specifications
Brand Name :
TECGEN Air Cooled Diesel Generator
Model Number :
TG
Place of Origin :
China
Certification :
ISO / CE / SASO / SONCAP
MOQ :
1 SET
Price :
Negotiation
Packaging Details :
By Carton
Delivery Time :
15 working days after received deposit
Payment Terms :
T/T / L/C
Supply Ability :
3000 Units Per Month
Frequency :
50Hz / 60Hz
Speed :
3000RPM / 3600RPM
Product :
Air Cooled Diesel Generator
Output Type :
AC Single Phase/Three Phase
Option :
ATS
Description

Portable Generator 50HZ Rated 4.5kW Diesel Generator Silent Type Air Cooled

Product Description:

Other Generators presents its Air Cooled Diesel Generator with the option of ATS. This generator has a model number of TG and is available in two speed options: 1500RPM and 1800RPM. It has an output type of AC Single Phase/Three Phase. This generator is equipped with a 100% Copper Dynamo which is a brushless alternator and an alternator for generator set. This ensures reliability and durability of the product. The Air Cooled Diesel Generator is the perfect choice for various applications and is sure to meet the expectations of the user.

Features:

  • Product Name: Air Cooled Diesel Generator
  • Model Number: TG
  • Frequency: 50Hz / 60Hz
  • Output Type: AC Single Phase/Three Phase
  • Speed: 3000RPM / 3600RPM
  • Option: ATS

Technical Parameters:

Model(silent type) DG3500SE DG5500SE DG6500SE
Rated frequency[Hz] 50
Rated voltage[V] 220
Rated output power[KW/KVA] 3 4.5 6
Max output power[KW/KVA] 3.3 5 6.5
Rated rotation speed[rpm] 3000
Power factor[cos@] 1
Phase number Single phase
Noise level[Db(A)@7m] 75
Excitation mode Self-excitation brush
Engine model Single cylinder,4-stroke,air-cooled,direct injection, diesel engine
Engine type SD178F SD186FA SD188F
Displacement[ml(cu/in)] 296 418 456
Starting system Electric start
Fuel 0#(summer) or -10#(winter) -35#(chillness) diesel oil
Lube CDgrade or SAE 10W-30,15W-40
Low oil pressure alert system With
Indications Voltage--yes and Current --No
Overall dimension(LxWxH)[mm] 950x565x770
Dry weight[kg] 100 170 175
Guarantee period 1 year 1 year 1 year
package carton carton carton
20'' container(pcs) 72 72 72

Applications:

TECGEN Air Cooled Diesel Generator with model number TG is an ideal product for those who are looking for a reliable power source. It is certified with ISO / CE / SASO / SONCAP, which guarantees the quality and safety of the product. The minimum order quantity of this product is 1 SET and the price is negotiable. The delivery time is 15 working days after receipt of the deposit. The payment terms are T/T / L/C with the supply ability up to 3000 units per month.

The output type of this product is AC Single Phase/Three Phase with its speed up to 1500RPM / 1800RPM. It has an optional Automatic Transfer Switch (ATS) to provide a reliable power supply. The brushless dynamo and alternator for genset are designed to ensure the sturdiness and durability of the air cooled diesel generator. The generator set is well packaged with a carton for safe and secure delivery.

Customization:

TECGEN Air Cooled Diesel Generator

Brand Name: TECGEN
Model Number: TG
Place of Origin: China
Certification: ISO / CE / SASO / SONCAP
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: By Carton
Delivery Time: 15 working days after received deposit
Payment Terms: T/T / L/C
Supply Ability: 3000 Units Per Month
Output Type: AC Single Phase/Three Phase
Option: ATS
Frequency: 50Hz / 60Hz
Speed: 1500RPM / 1800RPM

TECGEN Air Cooled Diesel Generator is equipped with a brushless AC alternator, 100% Copper Alternator, Brushless Alternator. It is of high quality and has passed ISO, CE, SASO and SONCAP certifications. The minimum order quantity is 1 set and the price is negotiable. It can be packed by carton and the delivery time is 15 working days after received the deposit. We accept payment terms of T/T and L/C. The supply ability is 3000 units per month. Both single phase and three phase output type are available. With the optional ATS, the frequency can be 50Hz or 60Hz and the speed can be 1500RPM or 1800RPM.

50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled50HZ Rated 4.5kW Portable Diesel Generator Silent Type Air Cooled

Support and Services:

Other Generators Technical Support and Services
  • 24/7 online technical support
  • Live chat support
  • Telephone support
  • Email support
  • On-site service
  • Full system maintenance
  • Troubleshooting assistance
  • Software updates
  • Hardware installation
  • Software installation
  • Data backup and recovery
