Quiet Portable Silent Small Diesel Generator 5KVA For Home Backup
Quiet Portable Silent Small Diesel Generator 5KVA For Home Backup
Quiet Portable Silent Small Diesel Generator 5KVA For Home Backup
Quiet Portable Silent Small Diesel Generator 5KVA For Home Backup
Quiet Portable Silent Small Diesel Generator 5KVA For Home Backup
Quiet Portable Silent Small Diesel Generator 5KVA For Home Backup
Specifications
Brand Name :
TECGEN Air Cooled Diesel Generator
Model Number :
TG
Place of Origin :
China
Certification :
ISO / CE / SASO / SONCAP
MOQ :
1 SET
Price :
Negotiation
Packaging Details :
By Carton
Delivery Time :
15 working days after received deposit
Payment Terms :
T/T / L/C
Supply Ability :
3000 Units Per Month
Frequency :
50Hz / 60Hz
Speed :
3000RPM / 3600RPM
Option :
ATS
Product :
Air Cooled Diesel Generator
Output Type :
AC Single Phase/Three Phase
Genset Type :
Silent Type
Description

Quiet Portable Generator Silent Small Diesel Generator 5KVA for Home Backup

Product Description:

The Other Generators TG series is a reliable and powerful air cooled diesel generator with advanced AC brushless alternator and 100% copper dynamo. It is designed for a wide range of industrial and commercial applications such as agriculture, construction, mining, and emergency power supply. The TG series offers two speed options of 1500RPM and 1800RPM and two frequency options of 50Hz and 60Hz. Additionally, the optional Automatic Transfer Switch (ATS) ensures smooth and continuous operation. The diesel generator is equipped with 100% copper generator to ensure maximum efficiency and durability.

Features:

  • Product Name: Portable Generators
  • Output Type: AC Single Phase/Three Phase
  • Product: Air Cooled Diesel Generator
  • Speed: 3000RPM / 3600RPM
  • Option: ATS
  • Silent Type
  • Electric Start
  • ATS

Technical Parameters:

Model(silent type) DG3500SE DG5500SE DG6500SE
Rated frequency[Hz] 50
Rated voltage[V] 220
Rated output power[KW/KVA] 3 4.5 6
Max output power[KW/KVA] 3.3 5 6.5
Rated rotation speed[rpm] 3000
Power factor[cos@] 1
Phase number Single phase
Noise level[Db(A)@7m] 75
Excitation mode Self-excitation brush
Engine model Single cylinder,4-stroke,air-cooled,direct injection, diesel engine
Engine type SD178F SD186FA SD188F
Displacement[ml(cu/in)] 296 418 456
Starting system Electric start
Fuel 0#(summer) or -10#(winter) -35#(chillness) diesel oil
Lube CDgrade or SAE 10W-30,15W-40
Low oil pressure alert system With
Indications Voltage--yes and Current --No
Overall dimension(LxWxH)[mm] 950x565x770
Dry weight[kg] 100 170 175
Guarantee period 1 year 1 year 1 year
package carton carton carton
20'' container(pcs) 72 72 72

Customization:

TECGEN Air Cooled Diesel Generator

Brand Name: TECGEN

Model Number: TG

Place of Origin: China

Certification: ISO / CE / SASO / SONCAP

Minimum Order Quantity: 1 SET

Price: Negotiation

Packaging Details: By Carton

Delivery Time: 15 working days after received deposit

Payment Terms: T/T / L/C

Supply Ability: 3000 Units Per Month

Output Type: AC Single Phase/Three Phase

Frequency: 50Hz / 60Hz

Option: ATS

Speed: 3000RPM / 3600RPM

Quiet Portable Silent Small Diesel Generator 5KVA For Home BackupQuiet Portable Silent Small Diesel Generator 5KVA For Home Backup

Support and Services:

Our technical support and service for Other Generators includes:

  • 24/7 email support
  • Phone support and technical advice
  • Updates and upgrades
  • Training and tutorials
  • Online technical assistance
  • Product warranties
