Yuchai 100kW Diesel Generator 125kVA Prime Ultra Silent Diesel Generator 1500rpm Diesel Generator for Home USE

Standard Configuration of 125kVA Yuchai Silent Type Diesel Generator Set

1. Powered by Yuchai engine

2. Tecgen alternator (Stamford, Meccalte for option)

3. Smartgen HGM 6120N control panel as standard, AMF Control Panel Deepsea DSE7320 & ComAp AMF20 for Option, ATS for Option

4) CHNT breaker as standard, ABB, Schneider Breaker for Option

5) 8 Working Hours Base Fuel Tank (for the genset ≤ 650kVA prime without based fuel tank)

6) Anti-Vibration Mounted System

7) Maintenance-free Battery and charged battery

8) Industrial silencer and flexible exhaust hose

For open type, the genset will be much easier to maintain and repair with more durable performance and longer service life

More technical datas

Our Yuchai gensets compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 Standard
Prime output power: 8KVA - 3000 KVA
Rated voltage: 120V/240V, 220/380V, 230V/400V, 254V/440V etc.
Phase/connecting: 3 phase, 4wire.
Rated frequency: 50Hz@1500rpm, 60Hz@1800rpm
Alternator excited type: Brushless, self excited or PMG
Insulation: Class H
Protection: IP21~IP23
Voltage regulation: AVR automatic control 1%
Altitude above sea level: ≤1000 meters
Ambient air temperature: ≤40°C
Relative air humidity: ≤ 90%

125kVA Yuchai SILENT DIESEL GENSET SPECIFICATIONS

100kW Yuchai Diesel Engine Driven Generator

Rated Power : 100kW / 125kVA

Frequency :50/60HZ

Speed :1500/1800rpm

Phase :3phase ; 1phase

Voltage: 110V - 460V

Fuel tank : 8 hours

Noise level : below 80dB(A)@7m

Environmental temperature : -5ºC ~ 50ºC

Water tank :50ºC environmental protection water tank

Diesel engine :Diesel , four stroke , water cooling

Alternator : brushless alternator /Marathon/Stamford

Controller : Smartgen / Deepsea / ComAp

Leading time: Normal 10 Working days

Starting method : Manual or electronic , adjustable

Package : Plastic warpping film or polywooeden

Export port : Fuzhou / Ningbo / Guangzhou / Shanghai / Qingdao Port

Optional parts : ATS ,water heater , fuel heater...

* Anti-vibration mountings on skid;

* Electrical start system with maintain free battery & engine driven battery charger;

* Residence silencer with flexible connections & elbow;

* Full set of Test report, drawings & manuals include.

FAQ (FREQUENCY ASKED QUESTION)

Question: What's your warranty period?

Answer: Our warranty terms is 1.5 year or 1500 running hours whichever comes first.

But based on some special project, we can extended our warranty period.

Question: Do you accept OEM/ODM service?

Answer: Yes, we can accept OEM & ODM service.

Question: What's your payment terms?

Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment.

Or 100% irrevocable confirmed L/C at sight.

Question: What's your delivery time?

Answer: Our normal delivery time is 7 - 15 working days.

But if your order is some special engine and alternator, then the delivery time is longer.

Question: What's the MOQ?

Answer: 1 Set
