Specifications
Brand Name :
Tecgen
Model Number :
TGWC-15M
Certification :
CE
Place of Origin :
Fuzhou, China
MOQ :
1 unit
Price :
3000$
Payment Terms :
L/C, T/T
Supply Ability :
100 Units Per Month
Delivery Time :
12 Days
Packaging Details :
Stretch film packaging
Application :
commercial
Controller :
Smartgen/Deepsea/ComAp
Cooling System :
Sea-weater Heater
Dimension :
L1300 x W630 x H1000mm
Frequency :
50Hz/60Hz
Fuel :
Diesel
Noise Level :
≤80dB(A)
Output :
12kW / 15kVA
Speed :
1500rpm/1800rpm
Type :
Marine Generators
Voltage :
220V-690V
Warranty :
1-2 Years
Weight :
650kgs
Description

Weichai 12kW/15kVA Marine Diesel Generator w/12-Month Warranty

Products: Weichai 12kW/15kVA Marine Diesel Generator w/12-Month Warranty

Prime Output: 12kW

Payment Term One: 30% Paid By T/T for Deposit, 70% Paid by T/T Before Shipment.

Payment Term Two: 100% Paid by Irrevocable L/C At Sight.

Engine Manufacturer: Weichai Group

Warranty: 12 months or 1,000 running hours, subject to which comes first.

Supply Scope: Diesel engine, Alternator, Automatic start / stop control panel, Dry type air fillter, fuel filter, oil filter, 4V D.C automatic battery charger, Sea-water Heater, Batteries, rack and cable, Ripple flex exhaust pipe, flange and muffler, Circuit breaker, Base Fuel tank, Complete users' manual.

Testing: Tecgen Power provides a full line of brand new and high quality products. Every unit is strictly factory tested.

Services Parts: Service and parts are avaiable from Tecgen Power or distributors in your location.

Weichai 12kW 15kVA Diesel Marine Generator 220V-690V Commercial

TECHNICAL DATA:

Technical Specification:
Marine Diesel Generator Set Specification
Marine Genset Model TGWC-15M
Open
Frequency 60Hz
Voltage 120V
Phase 3
Rate Current 72.2A
Prime Power 12kW / 15kVA
Standby Power
Engine Model WP2.3CD25E200
Alternator Model TGM-10-4
Controller HGM6120N
Weight & Dimensions
Length (mm) 1300
Width (mm) 630
Height (mm) 1000
Weight (kgs) 650
Engine Specification
Brand Weichai
Engine Model WP2.3CD25E200
Standby power (kW) 25
Injection Indirect
Aspiration Four Stroke, Water-Cooled, Inline, Wet Cylinder Liner
No. of cylinders 4
Bore of Stroke (mm) 89 x 92
Displacement (L) 2.289
Cooling Sea Water Pump
Compression Ratio 17.3:1
Governor MECH
Air Filter Dry Element
Fuel consumption at 60Hz
100% Load (L/h) 3.3
Alternator Specification
Brand Tecgen
Model TGM-10-4
Rate Output (kVA) 15
Pole 4
Winding Connections Star
Insulation Class H
Enclosure IP23
Altitude (m) ≤1000
Voltage Regulator AVR
Steady State Voltage Regulator 1%
Bearing Double
Controller System
Brand Smartgen
Model HGM6120N
Functions Control with AMF module
Static with auto. battery charger
Emergency stop push button
ATS Connection
OPTIONAL EQUIPMENTS
ATS Box, Switch Box, Remote Control, Daily Fuel Tank, Engine Heater, Water Heater, PMG Generator, Parallel Panel, Fuel-water separator, Trailer Type, 3000Hours Spare Parts

Weichai 12kW 15kVA Diesel Marine Generator 220V-690V Commercial

Tecgen Power Generator Feature:

1, Output range: 10kVA to 3000kVA Heavy Duty diesel generator.

2, Different brands of engine, alternator and controller as options

3, Coupled with Stamford alternator, Marathon alternator or Chinese Tecgen Power alternator

4, Open type, silent type, super silent type or mobile type generator.

5, CE, ISO9001-2008, SONCAP, SASO and SGS certified

6, Starter System with maintenance-free battery

7, Control Panel with Key Start (Power Switch)

8, With 100% fire-resistant sound attenuating sponge

9, 10% of rate output of overload for 1hours in every 12hours

10, Spare parts are easy to get from worldwide market with much cheaper price

11, Perfect after-service network

12, Both 50Hz and 60Hz

13, Chint circuit breaker

14, Three-phase output meets differing requirements

15, ATS ( auto transfer switch for city power and generator power ) / AMF (auto mains failure) /parallel running for option

16, Working Hours Base Fuel Tank

17, Anti-Vibration Mounted

18, Industrial silencer and flexible exhaust hose

19, 0-110% load test for each unit before delivery

20, Warranty with 1000 hours or one year, which comes first.

perfect and luxury for advertising.

All stand machine can install wheel. It depends on your requirements. If we done this, the machine can move around easily.
