Specifications
Brand Name :
TECGEN Brushless Alternator
Model Number :
TGI
Place of Origin :
China
Certification :
ISO / CE / SASO / SONCAP
MOQ :
1 SET
Price :
Negotiation
Packaging Details :
Standard export package
Delivery Time :
10 Working Days
Payment Terms :
T/T / L/C
Supply Ability :
2000 Units Per Month
Type :
Brushless
Product :
TECGEN Brushless Alternator
Phase :
Single / Three Phase
Bearing :
Single/Double Bearing
Speed :
1500RPM / 1800RPM
Winding :
100% Copper
Frequency :
50Hz / 60Hz
Description

6.5-1000KVA Copy Stamford Brushless Alternator with 100% Copper Winding

Product Description:

Tecgen provides 100% AC Alternator with TGI Model Number. It is a TECGEN Brushless Alternator with single/double bearing. The winding is 100% copper and it is available in both single and three phase. Other Generators ST/STC alternator is also available for customers who require even more power. All of our products are of the highest quality, ensuring complete satisfaction for our customers.

Features:

  • Generator / Alternator: Brushless Generators
  • Winding: 100% Copper
  • Product: TECGEN Brushless Alternator
  • Bearing: Single / Double Bearing
  • Speed: 1500RPM / 1800RPM
  • Phase: Single / Three Phase

Technical Parameters:

Alternator Rate power: 6.5-1000KVA

Model Prime Output (1500rpm/50Hz) 400V Prime Output (1800rpm/60Hz) 440V
KVA KW KVA KW
TGI164A 8.1 6.5 10.2 8.2
TGI164B 11 8.8 13.8 11
TGI164C 13.5 10.8 16.9 13.5
TGI164D 16 12.8 20 16
TGI184E 22.5 18 28.8 23
TGI184F 27.5 22 34.4 27.5
TGI184G 31.3 24 37.5 30
TGI184H 37.5 30 46.9 37.5
TGI184J 40 32 50 40
TGI224C 42.5 34 52.5 42
TGI224D 50 40 62.5 50
TGI224E 60 48 70 56
TGI224F 72.5 58 87.5 70
TGI224G 85 68 97.5 78
TGI274C 100 80 117.5 94
TGI274D 120 96 137.5 110
TGI274E 140 112 167.5 134
TGI274F 160 128 190 152
TGI274G 180 144 218.5 174.8
TGI274H 200 160 245 196
TGI274J 230 184 281 224.8
TGI274K 250 200 299 239.2
TGI314C 250 200 294 235
TGI314D 295 236 350 280
TGI314E 325 260 394 315
TGI314F 380 304 456 365
TGI354C 450 360 550 440
TGI354D 500 400 594 475
TGI354E 600 480 713 570
TGI354F 670 536 775 620

Applications:

TECGEN Brushless Alternator, model TGI, is the perfect choice for a wide variety of settings. With our ISO / CE / SASO / SONCAP certification, this brushless alternator is the most reliable and cost-effective solution for all your power needs. This generator has a minimum order quantity of 1 SET and is priced for negotiation. The packaging is of standard export quality and the delivery time is 10 working days. We accept both T/T and L/C as payment terms. With a supply capacity of 2000 Units per month, this brushless alternator is the perfect choice for your power needs. This TECGEN Brushless Alternator has a winding of 100% copper and is available in both 1500RPM and 1800RPM. It also has single and double bearing options available.

Customization:

TECGEN Brushless Alternator

This is the perfect 100% copper alternator. It is a TECGEN brushless alternator with model number TGI. It is certified with ISO, CE, SASO and SONCAP. The minimum order quantity is 1 SET and the price is negotiable. It is packed in a standard export package and the delivery time is 10 working days. The payment terms are T/T or L/C and the supply ability is 2000 units per month. The phase is single or three phase and the speed is 1500RPM or 1800RPM. This product is 100% brushless and 100% AC alternator with single or double bearing.

6.5-1000KVA Copy Stamford Brushless Alternator With 100% Copper Winding

Support and Services:

Technical Support and Service for Other Generators

At Other Generators, we are committed to offering the best customer service and technical support in the industry. Our team of highly qualified and experienced technical support representatives are available 24/7 to answer your questions and resolve any issues you may be having with our products.

We offer a wide range of services to ensure you get the most out of your Other Generators product, including:

  • Comprehensive troubleshooting and maintenance services
  • Expert advice on the best way to use our products
  • Updates on the latest product releases
  • Assistance with product installation and setup
  • Software and firmware downloads

We strive to provide the highest quality customer service and technical support to our customers. If you have any questions or need assistance with our products, please don't hesitate to contact us.
