Specifications
Brand Name :
TECGEN Brushless Alternator
Model Number :
TGI
Place of Origin :
China
Certification :
ISO / CE / SASO / SONCAP
MOQ :
1 SET
Price :
Negotiation
Packaging Details :
Standard export package
Delivery Time :
10 Working Days
Payment Terms :
T/T / L/C
Supply Ability :
2000 Units Per Month
Bearing :
Single/Double Bearing
Speed :
1500RPM / 1800RPM
Winding :
100% Copper
Frequency :
50Hz / 60Hz
Product :
TECGEN Brushless Alternator
Phase :
Single / Three Phase
Type :
Brushless
Description

Single Phase/Three Phase TECGEN Brushless Alternator Stamford Type Alternator

Product Description:
Other Generators offers a TECGEN Brushless Alternator which is perfect for AC applications. This AC Brush Alternator offers a single or three phase winding of 100% copper, providing a reliable and durable solution.

Features:

  • Product Name: Brushless AC Alternator
  • Bearing: Single/Double Bearing
  • Phase: Single/Three Phase
  • Frequency: 50Hz/60Hz
  • Model Number: TGI
  • Winding: 100% Copper
  • Brush Dynamo: Yes
  • 100% Copper Dynamo: Yes
  • Brush Dynamo: Yes

Technical Parameters:

Alternator Rate power: 6.5-1000KVA

Model Prime Output (1500rpm/50Hz) 400V Prime Output (1800rpm/60Hz) 440V
KVA KW KVA KW
TGI164A 8.1 6.5 10.2 8.2
TGI164B 11 8.8 13.8 11
TGI164C 13.5 10.8 16.9 13.5
TGI164D 16 12.8 20 16
TGI184E 22.5 18 28.8 23
TGI184F 27.5 22 34.4 27.5
TGI184G 31.3 24 37.5 30
TGI184H 37.5 30 46.9 37.5
TGI184J 40 32 50 40
TGI224C 42.5 34 52.5 42
TGI224D 50 40 62.5 50
TGI224E 60 48 70 56
TGI224F 72.5 58 87.5 70
TGI224G 85 68 97.5 78
TGI274C 100 80 117.5 94
TGI274D 120 96 137.5 110
TGI274E 140 112 167.5 134
TGI274F 160 128 190 152
TGI274G 180 144 218.5 174.8
TGI274H 200 160 245 196
TGI274J 230 184 281 224.8
TGI274K 250 200 299 239.2
TGI314C 250 200 294 235
TGI314D 295 236 350 280
TGI314E 325 260 394 315
TGI314F 380 304 456 365
TGI354C 450 360 550 440
TGI354D 500 400 594 475
TGI354E 600 480 713 570
TGI354F 670 536 775 620

Single Phase Three Phase TECGEN Brushless Alternator Stamford Type Alternator

Customization:

Other Generators

We provide 100% brushless st/stc dynamo generators from TECGEN, with certification from ISO / CE / SASO / SONCAP. Our brushless alternators come with a model number of TGI, and have a minimum order quantity of 1 SET. Prices are negotiable, and delivery time is 10 working days. We accept payment terms of T/T / L/C, and our supply ability is 2000 units per month. Our generators/alternators come with speeds of 1500RPM / 1800RPM, bearing types of single/double bearing, and frequency of 50Hz / 60Hz.

Support and Services:

We provide technical support and service for Other Generators. Our technical support team is available 24/7 to answer your questions and help you solve any issues you may have. We also offer a variety of services, such as installation and maintenance, training and troubleshooting, that can help you get the most out of your Other Generators product.
