Specifications
Brand Name :
DGAX
Model Number :
StreT
Certification :
CE
Place of Origin :
Dongguan,China
MOQ :
1set
Price :
Contact Us
Payment Terms :
T/T
Supply Ability :
100sets/month
Delivery Time :
45-60days
Packaging Details :
Foam inner+ exported wooden case
Function :
Products appearance defect inspection
Application :
Rubbers, Plastics,Cable...
Warranty :
1 Year
Core Components :
AI intelligence,Servo Motor, PLC, cylinder,CCD Camera,
Power supply :
AC220V±10% 50HZ/60HZ
Efficiency :
100pcs/h (Depends on size and material )
Volume :
Feeding device 300L
Quantity of Camera :
Depends on detection requirement
Description

Intelligent visual inspection machine to check close crack detection

Key Features

✔ Sub-Micron Crack Detection – Identifies closed/hairline cracks as fine as 5μm
✔ Multi-Spectral Imaging – Combines UV fluorescence + polarized light + thermal imaging
✔ AI-Powered Analysis – Distinguishes:
→ Surface-breaking cracks (even with no visible gap)
→ Subsurface defects (via thermal diffusion analysis)
→ Stress concentration zones (predictive failure points)

Technical Specifications

  • Optical Resolution: 25MP camera + 10X optical zoom

  • Detection Sensitivity:

    • Surface cracks: ≥5μm width

    • Subsurface flaws: ≥0.1mm depth

  • Inspection Speed: 100mm²/sec (adjustable scan density)

  • Lighting System:

    • UV excitation (365nm) for micro-crack highlighting

    • Cross-polarized lighting for stress visualization

Target Applications

  • Metal Components: Engine blocks, turbine blades

  • Ceramics: Insulators, biomedical implants

  • Composite Materials: Aerospace structures, pressure vessels

Advanced Detection Modes

Technology Crack Type Detected Depth Penetration
UV Fluorescence Surface-breaking 10μm
Lock-In Thermography Subsurface 2mm
Digital Image Correlation Stress-induced micro-cracks N/A (surface strain)

Smart Features

→ 3D Crack Mapping – Quantifies length/depth/orientation
→ Self-Learning Database – Improves detection for new materials
→ Predictive Maintenance – Tracks crack propagation over time
