ISO 60Hz Assembly Smt Pcb Conveyor 300W Max. Mobile Industry Use
ISO 60Hz Assembly Smt Pcb Conveyor 300W Max. Mobile Industry Use
ISO 60Hz Assembly Smt Pcb Conveyor 300W Max. Mobile Industry Use
ISO 60Hz Assembly Smt Pcb Conveyor 300W Max. Mobile Industry Use
Specifications
Brand Name :
SMTfly
Model Number :
SMTfly-FL
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
300 sets per month
Delivery Time :
5-10 days after receive the payment
Packaging Details :
each set be packed in plywood case
Product name :
PCB Flipper/inverter
PCB Size(mm) :
50*50-445*330
Specification :
CE /UL
Dimension(mm) :
500*786*1200
PCB Direction :
L to R or R to L
PCB Capacity :
12 PCS or Specify
Cycle Time :
Approx.5 Seconds
Power Supply :
1 pH AC 220V 50/60Hz
Description

PCB Turuing Conveyir SMT Handling Equipment Flipper

The Buffer is used as a buffer between SMT machines. The Buffer does not use transport belts, but uses durable rollers to convey the PCB’s. The module is very easy to operate and has a very small footprint for the manufacturing where space is an issue.

Features

  • User-friendly soft-touch LED membrane control panel
  • Pass-through modes selectable
  • Durable rollers as conveying transport (no belts)
  • Smooth and parallel width adjustment (lead screw)
  • Conveyor height 950±30mm
  • SMEMA compatible

Technical Parameters

  • Description – This unit is used as a buffer between SMT machines.
  • Power Consumption – AC 220V, 50/60Hz, 1 phase
  • Cycle Time – Approx. 8 seconds
  • Max. PCB Capacity – 20 pcs only
  • Air Pressure & Consume – 4-6 bar, 15 l/min Max.
  • Indexing Pitch – 10, 20 mm or specify
  • Power Source – 300W Max.

ISO 60Hz Assembly Smt Pcb Conveyor 300W Max. Mobile Industry Use

Specifications

  • Size – M
  • Model – SMTfly-FL
  • Machine Dimensions (mm) (LxWxH) – 544 x 1112 x 1694
  • Effective PCB Size (mm) – 50 x 50 – 330 x 250
  • Weight (Kg) – 300
