150kv Medical Fiber Laser Collimator , Mobile X Ray Machine High Power Fiber Collimator
150kv Medical Fiber Laser Collimator , Mobile X Ray Machine High Power Fiber Collimator
Specifications
Brand Name :
SAILRAY
Model Number :
SRF301N
Place of Origin :
CHINA
MOQ :
4
Payment Terms :
T/T, Western Union
Supply Ability :
100 per month
Delivery Time :
30 work days
Packaging Details :
Wooden Case
Lamp :
LED
Max Voltage :
150KV
Shell Material :
Iron Shell
contrast ratio :
>4:1
Model No :
SRF301N
Control Method :
Electric/Manual
Dimension(mm) :
210×285×170
Price :
Negotiation
Description

150kv Medical CR DR Equipment X-ray Beam Collimation of SRF301N

X-ray beam collimator is a must to reduce radiation exposure and to obtain the best image. Our collimators ensure quick collimation every time.

Applications:

This x-ray collimator is applicable for 3.5KW,10KW Bed mobile x-ray machine.

Technical parameters:

Max Voltage 150KV
Maximum X-ray field coverage range 480mm×480mm (SID=100cm)
The average brightness of the light field >160 lux
Edge contrast ratio >4:1
Power supply requirement of projection lamp 24V AC/150W
Bright X-ray field duration for Once 30S
Distance from Focal Spot of X-ray tube to the mount plane of collimator SID (mm)(optional) 60
Filtration(Inherent) 75kV 1mmAl
Filtration(Additional) The outer optional
Control method Electric/Manual
Drive motor --
Motor Control --
Position detection --
Input power AC24V/DC24V
(SID)Measuring tape Standard Configuration
Center laser instructions optional
Dimension(mm)(W×L×H) 210×285×170
Weight(Kg) 8.8

Detailed Images

150kv Medical Fiber Laser Collimator , Mobile X Ray Machine High Power Fiber Collimator
