Specifications
Brand Name :
Dehray
Model Number :
RDE12STA
Certification :
CE, EU 5
Place of Origin :
China
MOQ :
1
Price :
USD
Payment Terms :
T/T,L/C,Western Union
Supply Ability :
1 per week
Delivery Time :
2 weeks
Packaging Details :
Plywood board + corrugated box
Model No :
RDE12STA
Rated Power :
8.5Kw
Max Power :
9.5Kw
Rated Frequency :
50Hz
Voltage :
115/230V
Power Source :
Electric
Generator Type :
V-twin,four stroke,swirl chamber,water-cooled diesel engine
Rated Speed :
1500r/min
Warranty :
1 Year
Engine Brand :
DEHARY
Generator Brand :
Faraday
Description
9KW Diesel Generator Set 230V Portable Generator Home Use with One Year Warranty

The dehray 9KW Diesel Generator offers 8.5kW rated power and 9.5 kW max power, operating at 115V/230V with a noise level of 53 dB for quiet performance. It features a 105L fuel capacity, 10h runtime, recoil start, and advanced tech like parallel function and LED display. Certified by ISO, CE, ensuring compliance with global safety standards and providing market access assurance.

Specifications

Genset Model RDE12STA/TAi
Generator set Rated frequency Hz 50 60
Prime power kVA 8.5 9
kW 8.5 9
Standby power kVA 9.5 10
kW 9.5 10
Rated voltage V 115/230 120/240
Rated current A 73.9/37 75/37.5
Rated rotation speed r/min 3000 3600
Alternator Alternator model KT12
NO. of pole 2
NO. of phase Single phase
Excitation mode Self excitation constant voltage w/AVR
i: w/iAVR
Power factor cosΦ 1.0
Insulation grade F
Engine Engine model RD2V80G
Engine structure V-twin,four stroke,swirl chamber,water-cooled
Bore×Sroke mm 80×79
Total displacement mL 794
Compression ratio 23:1
Rated power kW 12.5 14.5
Lubrication mode Pressure splashed
Lube grade Above CD or SAE 10-30,15W-40
Lube capacity L 2.27
Starting mode 12V electric start
Battery capacity 12V 36Ah
Fuel consumption 285 297
Fuel type Diesel:0#(summer),-10#(winter),-35#(chilliness)
Generator set Display panel HGM4020N
Output Socket 2-single phase
Terminal post Available
DC12V output N/A
Noise level(7m) dB/A 72
Fuel tank capacity L 26
Overall dimension mm 1350×650×760
Net weight kg 310
Packing Packing mode Plywood pallet+Carton
Packing dimension mm 1325*700*880
Gross weight kg 325
