Specifications
Brand Name :
KN
Model Number :
KN-R04
Certification :
ISO CE
Place of Origin :
Hebei,China
MOQ :
100 rolls
Price :
USD12.68-USD32.98
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000 pcs/week
Delivery Time :
7-15 days
Packaging Details :
Customized
Concertina Cross Type :
Single Cross ( without Clips)
Color :
Silver
Quality :
High, Top, Brand New
Coil Type :
Cross Type Concertina Wire
Razor Barb Spacing :
100±2mm
Barb Width :
13mm-32mm
Corrosionresistance :
High
Usage :
Security Fencing
Razor Blade Style :
Razor Blade Style
Barb Spacing :
26-100mm
Strand Structure :
Single strand
Frame Material :
Metal
Alias :
razor wire mesh fence
Shape :
Spiny
Rollweight :
15 kg
Description

KN Galvanized Barbed Wire Security Fencing With Barbed Blade From China Razor Wire

Product description

Razor Barbed Wire, also known as barbed wire breeding net, is used for fencing in farms, livestock areas, gardens, highways, factories, mining sites, and other protective applications. Its main features include convenient transportation and easy installation. The unique thorn shape minimizes contact risk while providing excellent protection. Razor wire consists of sharp edges or barbs that create a strong physical and psychological barrier. It is difficult to climb over or cut without specialized tools. Commonly found in high-security facilities and atop fences around commercial, industrial, and residential properties where security is essential.

KN Galvanized Barbed Wire Security Fencing With Barbed Blade From China Razor Wire

Product Details

Razor Blade Style and Specs
Reference Number
Blade Thickness
Wire Dia
Blade Length
Blade Width
Blade Spacing
BTO-10
0.5±0.05
2.5±0.1
10±1
13±1
26±1
BTO-12
0.5±0.05
2.5±0.1
12±1
15±1
26±1
BTO-18
0.5±0.05
2.5±0.1
18±1
15±1
33±1
BTO-22
0.5±0.05
2.5±0.1
22±1
15±1
34±1
BTO-28
0.5±0.05
2.5
28
15
45±1
BTO-30
0.5±0.05
2.5
30
18
45±1
CBT-60
0.6±0.05
2.5±0.1
60±2
32±1
100±2
CBT-65
0.6±0.05
2.5±0.1
65±2
21±1
100±2

Barbed Tape Wire Specification
Outside Diameter
No. of Loops
Standard Length per Coil
Type
Notes
500mm
56
12-13M
CBT-60.65
Single coil
700mm
56
13-14M
CBT-60.65
Single coil
960mm
56
14-15M
CBT-60.65
Single coil
450mm
56
8-9M (3 CLIPS)
BTO-10.12.18.22.28.30
Cross type
500mm
56
9-10M (3 CLIPS)
BTO-10.12.18.22.28.30
Cross type
600mm
56
10-11M (3 CLIPS)
BTO-10.12.18.22.28.30
Cross type
600mm
56
8-10M (5 CLIPS)
BTO-10.12.18.22.28.30
Cross type
700mm
56
10-12M (5 CLIPS)
BTO-10.12.18.22.28.30
Cross type
800mm
56
11-13M (5 CLIPS)
BTO-10.12.18.22.28.30
Cross type
900mm
56
12-14M (5 CLIPS)
BTO-10.12.18.22.28.30
Cross type
960mm
56
13-15M (5 CLIPS)
BTO-10.12.18.22.28.30
Cross type
980mm
56
14-16M (5 CLIPS)
BTO-10.12.18.22.28.30
Cross type

KN Galvanized Barbed Wire Security Fencing With Barbed Blade From China Razor WireKN Galvanized Barbed Wire Security Fencing With Barbed Blade From China Razor Wire

Installation Method
The installation of barbed wire generally requires iron posts or wooden stakes as supports. The barbed wire is pulled tight and
fixed to the supports. Depending on the environment and protection requirements, the height and density of the barbed wire can
vary.
Safety
Due to the sharpness of the barbs, special attention should be paid to safety during installation and use to avoid causing harm to
people and animals. Regular inspections and maintenance are also needed to ensure its continuous effectiveness for protection.
