W209PPB4 Agricultural Machinery Bearing 39*85*85mm Agriculture Bearings bearing With Square Hole
W209PPB4 Agricultural Machinery Bearing Description:
Model Number | W209PPB4 |
Seal Type: | Double Shielded, 2RS |
Material: | Chrome steel, Gcr15 |
Precision Rating: | P0-P5 |
BCA/FEDERAL MOGUL | DC214TTR2 |
FAFNIR/TORRINGTON | GW214PP2 |
W209PPB4 Agricultural Machinery Bearing
more models:
Bearing type | Style | d | D | Be | Bi | Dynamic load | The static load | Weight Lbs. |
GW209PPB2 | 3 | 1.7717 | 3.3465 | 1.1880 | 1.1880 | 7350 | 4150 | 1.44 |
45.000 | 85.000 | 30.175 | 30.175 | |||||
GW209PPB4 | 3 | 1.5350 | 3.3465 | 1.1880 | 1.1880 | 7350 | 4150 | 1.65 |
39.000 | 85.000 | 30.175 | 30.175 | |||||
GW209PPB11 | 1 | 1.7810 | 3.3465 | 0.8660 | 1.4380 | 7350 | 4150 | 1.37 |
45.237 | 85.000 | 22.000 | 36.525 | |||||
GW210PPB2 | 3 | 1.9380 | 3.5433 | 1.1880 | 1.1880 | 7880 | 4650 | 1.50 |
49.225 | 90.000 | 30.175 | 30.175 | |||||
GW210PPB5 | 3 | 1.7850 | 3.5433 | 1.1880 | 1.1880 | 7880 | 4650 | 1.8 |
45.339 | 90.000 | 30.175 | 30.175 | |||||
GW210PP9 | 5 | 1.9450 | 3.5433 | 0.9060 | 1.4380 | 7880 | 4650 | 1.75 |
49.403 | 90.000 | 23.000 | 36.525 | |||||
GW211PP2 | 4 | 2.1880 | 3.9370 | 1.3120 | 1.3120 | 9740 | 5850 | 3.00 |
55.575 | 100.000 | 33.325 | 33.325 | |||||
GW211PPB2 | 3 | 2.1880 | 3.9370 | 1.3120 | 1.3120 | 9740 | 5850 | 2.62 |
55.575 | 100.000 | 33.325 | 33.325 | |||||
GW211PPB8 | 1 | 2.1880 | 3.9370 | 0.9840 | 1.3120 | 9740 | 5850 | 1.85 |
55.575 | 100.000 | 25.000 | 33.325 | |||||
GW211PPB9 | 1 | 2.1950 | 3.9370 | 0.9840 | 1.5620 | 9740 | 5850 | 2.02 |
55.753 | 100.000 | 25.000 | 39.675 | |||||
GW211PPB10 | 3 | 1.9380 | 3.9370 | 1.3120 | 1.3120 | 9740 | 5850 | 2.26 |
49.225 | 100.000 | 33.325 | 33.325 | |||||
GW211PPB13 | 1 | 1.7850 | 3.9370 | 0.9840 | 1.3120 | 9740 | 5850 | 2.02 |
45.339 | 100.000 | 25.000 | 33.325 | |||||
GW211PPB14 | 1 | 2.0150 | 3.9370 | 0.9840 | 1.3120 | 9740 | 5850 | 2.00 |
51.181 | 100.000 | 25.000 | 33.325 | |||||
GW211PP25 | 5 | 1.7800 | 3.9370 | 1.3120 | 1.7500 | 9740 | 5850 | 2.44 |
45.212 | 100.000 | 33.325 | 44.450 | |||||
GW214PP2 | 4 | 2.7559 | 4.9213 | 1.5620 | 1.5620 | 14000 | 8800 | 4.19 |
70.000 | 125.000 | 39.675 | 39.675 | |||||
GW214PPB2 | 3 | 2.7559 | 4.9213 | 1.5620 | 1.5620 | 14000 | 8800 | 3.96 |
70.000 | 125.000 | 39.675 | 39.675 | |||||
GW214PPB3 | 3 | 1.9380 | 4.9213 | 1.5620 | 1.5620 | 14000 | 8800 | 4.24 |
49.225 | 125.000 | 39.675 | 39.675 | |||||
GW214PPB5 | 2 | 2.7559 | 4.9213 | 1.5620 | 2.4380 | 14000 | 8800 | 4.75 |
70.000 | 125.000 | 39.675 | 61.925 | |||||
GW214PPB6 | 1 | 2.6881 | 4.9213 | 1.1024 | 2.6875 | 14000 | 8800 | 5.14 |
68.278 | 125.000 | 28.000 | 68.263 |
W209PPB4 Agricultural Machinery Bearing Advantages:
1. High operation precision;
2. Most rolling bearings can also be subjected to radial and axial loads, so the combined structure of bearings is simple;
3. For axle diameters of the same size, the width of rolling bearing is smaller than that of sliding bearing, which can make the axial structure of machinery compact;
4. Under ordinary conditions, the efficiency of rolling bearing is equal to that of hydrodynamic smooth bearing, but higher than that of inclusion smooth bearing.
