ABB 3BHE022294R0101 GFD233A Industrial Control Board for AC 800PEC GMD Drive Systems
ABB 3BHE022294R0101 GFD233A Industrial Control Board for AC 800PEC GMD Drive Systems
ABB 3BHE022294R0101 GFD233A Industrial Control Board for AC 800PEC GMD Drive Systems
ABB 3BHE022294R0101 GFD233A Industrial Control Board for AC 800PEC GMD Drive Systems
ABB 3BHE022294R0101 GFD233A Industrial Control Board for AC 800PEC GMD Drive Systems
ABB 3BHE022294R0101 GFD233A Industrial Control Board for AC 800PEC GMD Drive Systems
Specifications
Place of Origin :
SWEDEN
Delivery Time :
2-3 work days
MOQ :
1
Brand Name :
ABB
Payment Terms :
T/T
Description




AMIKON INDUSTRIAL SUPPLY
INDUSTRIAL COMPONENT SOURCING
ABB / HARDWARE REFERENCE
PART IDENTIFICATION

3BHE022294R0101

An industrial control-interface board identified by article number 3BHE022294R0101. Confirm the complete article number, board marking and revision before sourcing a replacement.






MANUFACTURER
ABB
ARTICLE NUMBER
3BHE022294R0101
BOARD MARKING
GF D233 A101
01 / SYSTEM CONTEXT

APPLICATION & FAULT SCENARIOS

Application & Failure Scenarios

Relevant to maintenance and spare-parts identification for GMD cycloconverter drive-control systems using the AC 800PEC platform.

Communication faults

Review relevant controller communication paths during fault diagnosis.

Measurement anomalies

Abnormal current or voltage readings require system-level checks.

Gate-driver interface

Inspect associated interfaces when troubleshooting relevant faults.


DOWNTIME CONSIDERATION

A drive-control fault may delay operation or prevent restart, depending on the system configuration and protection response. Check alarm history and follow the approved diagnostic procedure before identifying a failed component.




02 / HARDWARE REFERENCE

Technical Specifications

Select either heading to view the identification details and hardware functions.

A Identification & System PART NUMBER & BOARD MARKING +
Manufacturer
ABB
Article number
3BHE022294R0101
Board marking
GF D233 A101
System
AC 800PEC GMD cycloconverter drive control
B Hardware Functions SIGNALS & INTERFACES +
Communication
Redundant optical communication links.
Gate-driver outputs
Optical outputs for medium-voltage thyristor gate-driver units.
Current inputs
Two current-measurement channels and one interface for an external current transducer.
Voltage inputs
Two differential voltage-measurement inputs with 10× high-resolution amplification.
Signal processing
Anti-aliasing filters and 14-bit ADCs operating at 1 MHz.
Digital inputs
Six 24 V inputs for contact-status monitoring.
Power supply
Redundant 24 V supply inputs.
Mounting
DIN-rail mounting.

The hardware functions above describe the GF D233 PEC80-LIN board type. Confirm that these functions match article 3BHE022294R0101 and the installed hardware revision before wiring, commissioning, repair or replacement.

03 / SERVICE NOTES

Maintenance & Identification

Before ordering, compare the complete article number, board marking and revision with the installed hardware. Review the event history and check relevant optical links, measurement signals, power connections and gate-driver interfaces according to the approved service procedure.


Similar designations or matching connectors alone do not establish interchangeability.
04 / ORDER SUPPORT

Delivery & Warranty



Testing

Part-number and visual checks; functional testing depends on availability and the written quotation.


Packaging

Protective packaging for transport.


DOA / Returns

Report arrival damage or suspected defects promptly with photos and test evidence. Obtain return authorization before shipping an item back.


Warranty

AMIKON standard 12-month warranty against confirmed product defects, subject to the written quotation and warranty terms. Misuse, incorrect installation and external damage are excluded.



05 / PRODUCT SUPPORT

Frequently Asked Questions




01 / What is the GF D233 PEC80-LIN board used for?
It is associated with AC 800PEC GMD drive control, including controller communication, gate-driver interfacing and measurement-related functions.
02 / Which system should I verify before ordering?
Confirm the installed drive-control architecture, then compare the board marking, article number and hardware revision.
03 / What information is needed to identify the correct board?
Provide the complete article number, board designation, revision, machine/system model and a clear photograph of the installed board label where possible.
04 / Can the board be installed without further configuration checks?
That cannot be confirmed from the designation alone. Check the hardware revision, system configuration and approved service instructions before replacement or recommissioning.
05 / What should I include in a quotation request?
Send the part number, quantity, destination, required date and machine/system model to help AMIKON assess the sourcing request.
