ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
Specifications
Model Number :
SPASI23
Quotation Time :
Quick Quote Within 24 Hours
Delivery Time :
2-3 work days
Price :
66USD
Packaging Details :
Brand new and original
Payment Terms :
T/T
Supply Ability :
in stock
Brand Name :
ABB
Packaging :
Original new packaging
Place of Origin :
SWEDEN
Place of shipment :
Xiamen,China
MOQ :
1
Condition :
100% Original
Description
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

ABB SPASI23 is an isolated analog input module for the Harmony rack I/O system. It handles up to 16 independently configured analog inputs and supports thermocouple, millivolt, RTD, and high-level signals.

The module performs A/D conversion, signal correction, calibration, cold-junction compensation, and engineering-unit conversion for supported inputs.

Technical Specifications
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
ManufacturerABB
Part NumberSPASI23
Product TypeIsolated Analog Input Module
SystemSymphony™ Enterprise Management and Control System / Harmony rack I/O
Channels16 analog inputs
A/D Resolution24-bit
Input TypesHigh-level, mV, thermocouple, 3-wire RTD
High-Level Ranges1-5 V, 0-5 V, 0-10 V, -10 to +10 V
mV Ranges-100 to +100 mV; 0-100 mV
ThermocouplesB, E, J, K, L, N, R, S, T, U and documented regional variants
RTD3-wire RTD configurations including platinum, nickel, and copper types
Power+5 VDC ±5%, 500 mA typical
Operating Temperature0 to 70 °C
System Compatibility
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

Original-System Compatibility
SPASI23 is designed for Harmony rack I/O within the Symphony™ Enterprise Management and Control System.

Historical Replacement
According to the ABB SPASI23 Analog Input Module User Manual (Document No. 2VAA001604), SPASI23 is documented as a replacement for SPASI03 and SPASI13. The manual also documents its relationship with IMASI23 for INFI 90 systems.

Applications & Maintenance
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

SPASI23 is used to acquire temperature, millivolt, and voltage signals in Harmony-based control systems.

Common maintenance scenarios include input signal faults, incorrect readings, configuration issues, and module replacement. The ABB manual includes troubleshooting and replacement procedures.

Installation Guidelines
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

Before installation, verify the module address, jumper settings, I/O expander-bus dipshunts, and termination-unit configuration.

For SPASI03/SPASI13 replacement, check the required resolution settings and power-supply capacity before commissioning.

Maintenance Procedures
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

The ABB manual covers troubleshooting, preventive maintenance, module inspection, repair, replacement, and installation checks.

Maintenance should be performed by qualified personnel following applicable system safety procedures.

Associated Hardware
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

NTAI06 is the documented analog input termination unit associated with the ASI/SPASI analog input module, providing field signal termination for the 16 input channels.

The installation documentation also covers the associated cable and termination arrangements used with the module.

Frequently Asked Questions
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel
What does SPASI23 delivery and warranty service include?
Testing, protective packaging, DOA support, return or replacement handling, and warranty coverage can be arranged according to the agreed order terms.
What information is needed for an SPASI23 RFQ?
Please provide Part Number, Quantity, Destination, Required Date, and Machine/System Model.
Is SPASI23 a replacement for earlier ASI modules?
The documentation identifies replacement relationships with SPASI03 and SPASI13 and documents its relationship with IMASI23. Configuration requirements should be checked before replacement.
What should be checked before installing a replacement?
Verify the module address, jumper settings, I/O expander-bus configuration, termination-unit settings, and controller configuration.
Is the termination unit included with SPASI23?
The NTAI06 is documented as associated termination hardware. Whether it is included in an order depends on the supplied part and quotation.
Available Inventory Models
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

Note: These models are listed as available inventory only and are not official or compatible replacement models for SPASI23.

  • 5CFCRD.4096-04
  • 5CFCRD.4096-06
  • 5CFCRD.8192-04
  • 5DLSD4.1001-00
  • 5DLSDL.1000-00
  • 5LS182.6-2
  • 5LS187.61
  • 5LS189.6
  • 5LS189.6-1
  • 5MP7150.101E-000
  • 5PC511.SX01-00
  • 5PC600
  • 5PC600.E855-02
  • 5PC600.E855-03
Support Services
ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel ABB SPASI23 Isolated Analog Input Module – Harmony Rack I/O, 16-Channel

Amikon supports industrial automation spare-part requirements with:

  • Pre-shipment testing
  • Protective packaging
  • DOA support
  • Return and replacement handling
  • Warranty support
  • After-sales assistance
Contact: Miya Zheng
WhatsApp: +86 180 2077 6792
