ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
Specifications
Price :
66USD
Packaging Details :
Brand new and original
Payment Terms :
T/T
Place of shipment :
Xiamen,China
Model Number :
IMMFP03
Supply Ability :
in stock
Delivery Time :
2-3 work days
Quotation Time :
Quick Quote Within 24 Hours
Brand Name :
ABB
Packaging :
Original new packaging
Place of Origin :
SWEDEN
Condition :
100% Original
MOQ :
1
Description
ABB IMMFP03 Multi-Function Processor Module
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
ABB IMMFP03 is a Multi-Function Processor module for the INFI 90 process control system, designed for multiple-loop analog control, sequential control, batch control, supervisory control, optimization, and other demanding process-control applications.
Technical Specifications

ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz

Model IMMFP03
Product Type Multi-Function Processor Module
System INFI 90
Processor 32-bit, 32 MHz
SRAM 2 MB total; 1.57 MB available
NVRAM 512 KB total; 441 KB available
ROM 512 KB
Power Requirement +5 VDC, 2 A
Typical Power Consumption 10 W
I/O Capacity Up to 64 I/O modules
IISAC01 Station Capacity Up to 64 at 40 kbaud
NDCS03 Station Capacity Up to 8 at 5 kbaud
Redundant Communication Link 8 MB maximum; 4 MB normal operation
Controlway 1 Mbps peer-to-peer communication
Controlway Capacity Up to 32 devices
Programming C, BASIC, Batch, Ladder, function blocks and user-defined functions
Operating Modes Configure, Execute, Error
Dimensions 35.56 × 177.80 × 298.45 mm
Weight 0.84 kg
Operating Temperature 0 to 70°C
Relative Humidity 0-95% up to 55°C; 0-45% at 70°C, noncondensing
Altitude Sea level to 3 km
Mounting One slot in the module mounting unit
Front Panel 16 CPU LEDs + 1 status LED
Technical Reference: Elsag Bailey I-E96-203C, IMMFP03 and IMMFP03B Multi-Function Processor Modules
System Compatibility
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
IMMFP03 is designed for INFI 90 systems and works within the system's I/O and control architecture. Associated hardware includes IMMPI01, NTMP01, NIMP01/NIMP02 and NKMP03.
No official successor or replacement model is specified for IMMFP03 in the available manufacturer documentation.
Applications & Operation
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
IMMFP03 is used in INFI 90 process-control applications requiring processor-based control and data processing, including analog loop control, sequential control and batch applications.
The manual provides troubleshooting procedures for processor errors, abnormal status indications, communication-related issues and other diagnostic conditions.
Because the module can execute process-control functions, taking an active MFP offline may affect the controlled process and can create a shutdown or process-upset risk.
Redundancy & Configuration
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
IMMFP03 supports redundant MFP configurations. A secondary processor can remain in standby and assume control when the primary MFP goes offline.
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
IMMFP03 uses hardware configuration settings for module address, bus speed, operating mode, memory and other module functions.
  • Before replacement, check the existing module's DIP-switch and jumper settings
  • Confirm the backplane and associated interface configuration
  • The module occupies one slot in the module mounting unit
Diagnostics & Maintenance
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
The front panel provides CPU and status LEDs for operating and diagnostic information.
Troubleshooting Functions:
  • Error-code identification
  • LED status checks
  • Diagnostic operation
  • Status reporting
  • Serial-port troubleshooting
  • Module replacement
ESD precautions should be followed when handling or replacing the module.
Frequently Asked Questions
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
  • Q1. Can IMMFP03 be installed directly into any INFI 90 rack?
    Replacement should be checked against the existing mounting-unit configuration and backplane connections before installation.
  • Q2. What hardware may be installed alongside IMMFP03?
    The documented configuration may include an IMMPI01 interface module, NTMP01 termination unit, NIMP01/NIMP02 termination modules and NKMP03 redundant MFP ribbon cable.
  • Q3. Does replacing an IMMFP03 require transferring configuration settings?
    Yes. The replacement procedure includes checking and transferring the required module configuration before returning the replacement to service.
  • Q4. What should be done before removing an installed IMMFP03?
    The controlled equipment should be secured before maintenance. Removing or adjusting an active module can upset the controlled process.
  • Q5. Is ESD protection required when handling IMMFP03?
    Yes. The module contains electrostatic-sensitive devices, so appropriate static-control procedures should be followed during handling and replacement.
  • Q6. What maintenance does the manufacturer recommend?
    The manual covers PCB cleaning, edge-connector cleaning, connection inspection and module replacement procedures.
  • Q7. What information should I provide when requesting an IMMFP03?
    Please provide Part Number, Quantity, Destination, Required Date and Machine/System Model. For compatibility review, photos of the existing module label and faceplate are also useful.
Related Available Inventory
ABB IMMFP03 Multi-Function Processor Module – INFI 90, 32-bit / 32 MHz
TTR200
6ES7322-1BL00-0AA0
CC-PCNT01
WK-2
MTL4041B
6ES7417-4HT14-0AB0
6SL3352-1AE35-0AA1
CC-TAOX11
CC-TAIX11
CC-TDIL01
BS30-R-CP6X
SK3110.000
3TX7003-1CB00
TM0182-A50-B00-C00
ACS-AP-I
IQ35F16B4
CC-PCNT02
51308386-176
51307715-176
These models are listed as available inventory only and are not official or compatible replacement models for IMMFP03.
