RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor
RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor
RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor
RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor
RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor
RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor
Specifications
Brand Name :
Lihua Motor/HCS Motors
Model Number :
RK-370SA-10760
Certification :
IATF16949/ISO9001/Reach/RoHs/SGS
Place of Origin :
Dongguan,China
MOQ :
2000PCS
Price :
Negotiation
Payment Terms :
L/C,T/T,D/A,D/P,Western Union
Supply Ability :
10000PCS/Day
Delivery Time :
35-45Days
Packaging Details :
Foam Carton
Motor Type :
RK-370SA-10760 Motor
Direction :
CW/CCW
OEM/OEM :
Available
Shaft Type :
Splined
Screw Hole Size :
3mm*0.5
Screw Hole Distance :
17mm±0.05
Motor Diameter :
24.4mm Max
Motor Length :
30.8±0.1mm(Without Shaft Length)
Name :
Mini DC Motor
Description

RF-370SA-10760 12 Volt DC Motor Electric Motor DC Motor 2000rpm-2700rpm Low Speed

RK-370 Motor Technical Specifications

  • Premium Quality DC Permanent Magnet Motors

    Our RF-370SA-10760 series represents industrial-grade brushed DC electric motors engineered for reliable performance in demanding applications. Available in 24 volt DC electric motor and 12V configurations, these direct current electric motors deliver optimized torque-speed characteristics with superior durability.

    Key Specifications:

    • Model Range: RK-370SA-10760 (24V) / RK-370CA-10760 (12V)

    • Voltage Options: 9V/12V/24V DC (3-24V operational range)

    • Speed Range: 2,000-4,400 RPM (model dependent)

    • Compact Dimensions: Ø24.4mm × 30.8mm (L)

    • Shaft Configurations:

      • Standard: 2.0mm diameter × 5mm length

      • Custom: Knurled shafts available (Ø2.02-2.05mm)

    • Weight: 50g (lightweight yet robust construction)

12 Volt DC Motor Electric Motor DC Motor 370 Mini Motor Dimension

RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor

24mm DC Motor Electric Motor DC Motor 370 Mini Motor TN Curve

RF-370SA-10760 12 Volt Electric Motor DC Motor 2000rpm-2700rpm Low Speed DC Motor

24mm 370 Mini Motor Technical Differentiation

1. 24 Volt DC Electric Motor Performance

  • RK-370SA-10760: 4,400 RPM @ ≤18mA (no-load)

  • RK-370SA-10760A: Precision knurled shaft variant (±0.02mm tolerance)

2. 12V DC Electric Engine Variants

  • RK-370SA-10760B: 2,200 RPM @ ≤15mA

  • RK-370CA-10760: 2,750 RPM @ ≤12mA (enhanced efficiency)

Core Technologies:
✔ Permanent Magnet Stator: Consistent torque output
✔ Precision Carbon Brushes: 500+ hour lifespan
✔ Class B Insulation: 85°C thermal tolerance

Performance Comparison

Model Voltage No-Load RPM Current Draw Key Feature
RK-370SA-10760 24V 4,400 ≤18mA Standard 24V
RK-370SA-10760A 24V 4,400±220 ≤18mA Knurled shaft
RK-370SA-10760B 12V 2,200 ≤15mA Low-current design
RK-370CA-10760 12V 2,750 ≤12mA High-efficiency

Lihua Motor /HCS Motor Customization Capabilities

As a specialist in DC permanent magnet motors, we offer:

  • Voltage-Specific Optimization: 3V-24V rewinding

  • Shaft Modifications: D-cut, flatted, or extended lengths

  • Bearing Upgrades: Oil-impregnated or ball bearing options

  • IP Rating Enhancements: Dust/waterproof sealing

Why Our Electric Motors?

  • 20+ Years in micro motor manufacturing

  • 1,200+ Custom Projects delivered globally

  • ISO 9001 & RoHS & Reach &CE &IATF16949 & ISO9001 certified production

24mm Motor Electric DC Industrial Applications

These direct current electric motors excel in:

Automation Systems

  • Conveyor belt drives

  • Packaging equipment feeders

Commercial Equipment

  • Vending machine mechanisms

  • ATM bill validator modules

Medical Devices

  • Surgical tool actuators

  • Dental equipment drives

Consumer Electronics

  • Professional camera gimbals

  • High-end audio turntables

Ordering & Support

MOQ: 2000 units (samples available)
Lead Time: 30 working days (standard)
Documentation:

  • Free 3D CAD files

  • EMI/EMC test reports

As a trusted supplier of small dc gear motor solutions, Lihua Motor manufactures high-quality mini dc motor with gearbox assemblies for industrial and consumer applications. Our small worm gear motor series delivers reliable torque output with customizable speed and voltage options to meet OEM requirements.
