40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor
Specifications
Brand Name :
CSJY
Model Number :
GMBS70ZF
Certification :
CE ROHS
Place of Origin :
CHINA
MOQ :
2PCS
Price :
Negotiate
Payment Terms :
L/C,T/T
Supply Ability :
5,000 in one month
Delivery Time :
7 to 15 days
Packaging Details :
carton
Rated power :
40W
Rated Current :
3A±10%
Ratio :
60:1
Nominal Voltage :
24VDC
Protection grade :
IP54
Rated Speed :
1800rpm±10%
Description

70mm*70mm 40W 24VDC Low-voltage Brushless Servo Motor For Turnstiles

Nominal Voltage 24VDC
Rated Current 3A±10%
Rated power 40W
Ambient temperature -25℃~55℃
Rated Speed 1800rpm±10%
Poles 4
Protection grade IP65
Noise ≤52dB
Rated Torque 9.2Nm
Line resistance ＞20MΩ

40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor

40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor

40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor

40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor


40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor

40W 24VDC 1800rpm Brushless Servo Motor for Turnstiles - Low-voltage DC Servo Motor



FAQ
1. Are you Factory or Trader?
we are factory,and have professional R.&D team as introduced in company information.
2. How can we guarantee quality?
Always a pre-production sample before mass production;Always final Inspection before shipment.
3. What can you buy from us?
Access servo drive,speed gate drive,turnstile controller,swing gate drive,barrier gate controller,servo motor,mechanism.
4. Why should you buy from us not from other suppliers?
We are with multiple invention patents and software copyrights such as servo drive and channel gate controltechnology.
Committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automaticgate control movement.
5. What is your after-sale service?
Free maintance within 12 months guarantee,lifetime consultant,Professional solutions in installation and maintance.
6. Do you get the relevant certifications?
All products are made according to ISO9001,CE requirements.
7. How about the delivery?
- Sample:3-5days
- Bulk order:15-30 days
