59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor
Specifications
Model Number :
GEBS59R-100A-20CP4E-A6JL-S0-03
Output speed :
100rpm
Payment Terms :
TT
Construction :
Permanent Magnet
Rated voltage :
DC24V
Price :
Negotiable
Continuous Current(A) :
6A
Efficiency :
IE 4
MOQ :
2pcs
Delivery Time :
10-15days after payment
Rated power :
100W
Supply Ability :
500pcs per month
Usage :
turnstile
Brand Name :
CSJY
Certification :
CE
Place of Origin :
China
Packaging Details :
package
Description

59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max

Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor.

IP65 Waterproof 59‑Frame 24V 100W Planetary Gear Servo Motor,‑25°C Cold‑Resistant, Max 23Nm

Torque Encoder Servo Motor For Flap‑Barrier, Swing‑Gate, Turnstile Access‑Control

Item Parameter
Rated Voltage 24 VDC
Rated Power 100 W
Reducer Ratio Standard 1:20, Optional 1:49
Max‑output Shaft Speed 100 RPM (1:20 gear) / 41 RPM (1:49 gear)
Max Output Torque 23 N·m
Encoder Resolution 2400‑line (9600 PPR) incremental encoder
Working Temperature Range ‑25 ℃ ~ +55 ℃
Flange Size 59 mm Round Flange
Motor Weight 1.6KG
Protection Grade IP65 Waterproof

59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor

59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor

59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor

59mm Flange 24V DC 100W Low‑Temperature‑Resistant Gear Integrated Servo Motor, 23Nm Max Torque 2400‑Line Encoder Feedback, Turnstile Speed Gate Barrier Gate Drive Motor

59mm flange 24V 100W integrated gear servo motor for speed‑gate turnstile,‑25℃ low‑temp resistant,

max 23Nm torque, 2400 line encoder feedback, IP65 waterproof access‑control barrier drive motor
