CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System
CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System
CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System
CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System
CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System
CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System
Specifications
Certification :
CE
Paper Length :
100-450mm
Place of Origin :
CHINA
Paper Width :
100-450mm
Total Power :
11KW/5KW
Footprint :
6000×2800mm
Brand Name :
DaYuan
Max. Production Speed :
600pcs/min
MOQ :
1
Edge Height :
15-230mm
Description

CE1000/2-B Dual Channel Full Servo Carton Forming Machine

Product Overview

The CE1000/2-B features an innovative dual-channel independent control design, enabling simultaneous production of cartons with completely different shapes and sizes. This solves the flexible production challenges of traditional single-channel or same-size dual-channel equipment.

Glue System Configuration: Standard equipment includes food-grade water-based glue forming process, with optional professional cold glue application system available for flexible selection based on product positioning, material characteristics, and cost requirements.

With eco-friendly forming process, stable operation, high efficiency, and clean production, this machine is ideal for eco-friendly paper packaging production under global "plastic ban" policies. Suitable for automatic production of hamburger boxes, hot dog boxes, Chinese food boxes, takeaway boxes, french fry boxes, bento boxes, and bakery cartons.

CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System

CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System

Featuring forward-looking modular architecture design, the machine has a mechanical physical lifespan exceeding 20 years and effective profitable lifespan over 15 years. It can be upgraded to adapt to new materials and processes, avoiding common industry investment waste.

Core Technical Advantages

Dual Channel Independent Control, Different Size Simultaneous Production

Core innovative advantage with dual-channel independent drive control system:

  • Two channels can produce cartons of completely different shapes and sizes simultaneously
  • Adapts to multi-batch and multi-specification customized orders with high flexibility
  • Maximum production speed up to 600pcs/min
  • Hamburger box forming speed: 100-120 pcs/min

Full Servo Precision Control System

Core forming unit uses servo drive scheme replacing traditional cam structure:

  • Servo motors precisely control forming mold movement
  • Higher positioning accuracy and more stable operation
  • Innovative vertical servo motor layout reduces horizontal space
  • Minimum installation footprint: 6000×2800mm
  • Full servo closed-loop control for consistent performance

  • CE1000/2-B Dual Channel Independent Control Full Servo Precision Carton Forming Machine with Optional Cold Glue System

Dual Glue System Options

  • Standard Food-Grade Water-Based Glue: Eco-friendly, odorless, complies with food contact safety standards
  • Optional Cold Glue Application System: Professional water-based cold adhesive, zero VOC emission, higher environmental protection grade

Wide Adaptation Range

  • Paper adaptation: length 100-450mm, width 100-450mm
  • Compatible with 200-600gsm cardboard, corrugated paper up to 1.5mm thick
  • Forming specification: edge height 15-230mm, maximum edge + lid height 260mm
  • Taper range: 5-40° adjustable

Forward-Looking Reinforced Architecture

15+ years effective profitable lifespan with:

  • Integrally welded thickened steel plate fuselage
  • High-strength alloy core transmission parts
  • Modular upgradable design for future adaptations
  • Reserved informatization interface for MES system integration

Core Technical Parameters

Item CE1000/2-B Technical Parameters
Model CE1000/2-B Dual Channel Carton Forming Machine
Working Mode Dual channel independent control
Power Supply 380V/50Hz
Total Power 11KW/5KW
Max. Production Speed 600pcs/min
Working Air Pressure 0.6MPa
Paper Dimensions Length 100-450mm, Width 100-450mm
Edge Height 15-230mm
Max. Edge + Lid Height 260mm
Taper Range 5-40°
Compatible Materials 200-600gsm cardboard; ≤1.5mm corrugated paper
Glue System Standard: food-grade water-based glue; Optional: cold glue system
Footprint 6000×2800mm (L×W)
Mechanical Lifespan Over 20 years
Effective Profitable Lifespan Over 15 years
Core Drive System Full servo independent control system
Certification EU CE Certification, ISO System Certification

Standard & Optional Configuration

Standard Configuration

  • Dual channel independent forming main machine
  • Automatic paper feeding mechanism
  • Food-grade water-based glue forming system
  • Full servo independent drive control system
  • Finished product output mechanism
  • Automatic fault alarm system
  • Thickened reinforced steel plate fuselage
  • CE standard electrical control system
  • 1 set of standard forming mold
  • Touch screen intelligent man-machine interface

Optional Configuration

  • Cold glue application system
  • Customized multi-specification molds
  • In-line visual inspection system
  • Automatic collecting & stacking device

Frequently Asked Questions

What is the difference between CE1000/2-B dual channel and ordinary dual channel models?
Ordinary dual channel models can only produce boxes of the same size and shape on both channels; while CE1000/2-B can produce two different boxes simultaneously, with stronger flexible production capability.
What is the maximum production speed of this equipment?
Maximum production speed reaches 600pcs/min. For lidded food boxes like hamburger boxes, forming speed is 100-120 pcs/min. Actual speed depends on paper size and material.
Can this machine be equipped with a cold glue system?
Yes. Standard configuration is food-grade water-based glue. Optional cold glue system uses professional water-based cold adhesive with zero VOC emission, higher environmental grade, better bonding strength and weather resistance.
What is the service life of this equipment?
Mechanical physical lifespan exceeds 20 years. Effective profitable lifespan reaches over 15 years due to modular upgradable architecture that adapts to new materials and processes.
