9V Carbon Robot DC Brush gearbox , customised Metal Gear Motor
9V Carbon Robot DC Brush gearbox , customised Metal Gear Motor
Specifications
Place of Origin :
China
Brand Name :
DAITTO
Certification :
ISO,CE
Model Number :
DA016017-16
MOQ :
500
Description
Type: DC Motor Brush Voltage: 9V Or Customised
Application: Mobile Telecommunication Base Station, Electric Curtain, Medical Device, Rotating Advertisement, Automatic Teller Machine, And Etc. Material: Metal
Diameter: 16mm Reduction Ratio: 16
Rated Load Torque: 120 Gf.cm Rated Load Speed: 391 Rpm
No Load Speed: 457 Rpm No Load Current: 77 MA MAX
Tolerance: 0.3mm

9V Carbon Robot DC Brush gearbox , customised Metal Gear Motor

Description

Parameters

diameter

16mm Gearbox, 17mm Motor

motor

DC brush motor

noise level

less than 40dB at the 50cm distance

life time

500 hours

working temperature

-40 to 95℃

tolerance

<0.3mm

Certification

ROHS/ISO9001/ISO14001/SGS/TS16949

Suitable for

Robot, Hair curler, Respirator, Automatic door & window, Monitoring equipment, and etc.

OSD Language

English, French, German, Italian, Russian, Spanish, Portuguese, Dutch, Greek, Japan, Korean

The basic specifications for reference only, specifications can be customized.

Specifications

Model No Load At Rated Load Max Rated Torque of Gear Box Max Instant Torque of Gear Box Transmission Reduction Overall Length L Gear Box Length L1
Speed Speed Current Torque Power
rpm rpm mA(MAX) gf.cm mN.m W gf.cm gf.cm Ratio Stage
DA016017-16 457 391 170 120 12 0.5 2000 6000 16/1 2 36.1 13.4
DA016017-24 304 260 170 180 18 0.5 2000 6000 24/1
DA016017-36 203 174 170 270 26 0.5 2000 6000 36/1
