Specifications
Place of Origin :
JIANGSU, CHINA
Brand Name :
TONGDA
Packaging Details :
PE film, PE bag, Wooden Cases, Wooden Pallet, etc.
Supply Ability :
800sets/year
Price :
$55,999.00 - $69,999.00/Sets
Certification :
CE, ISO9001
MOQ :
1SET
Delivery Time :
28 working days
Payment Terms :
T/T, L/C, D/P, West Union
Model Number :
TONGDA HS12L
Core Components :
PLC, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Plastic Processed :
PP, HDPE, PC, ABS, PVC, PE, EVA, PA, ABS/PP, PE/PP, HDPE/PP, PETG
Voltage :
Customized to customer needs
Dimension(L*W*H) :
5.21m*2.62m*3.2m
Hollow part volume :
1-12L
Clamping Force (kN) :
158
PLC Brand :
MITSUBISHI
Screw L/D Ratio :
25
Screw diameter (mm) :
80 mm
Output (kg/h) :
120 kg/h
Automation :
Automatic
No. of Screw Heating Zone :
3
Screw Heating Power(kW) :
7.8 kW
Extruder Motor Power(kW) :
30 kW
Mold Platen Size(Width)(mm) :
590 mm
Mold Platen Size(Height)(mm) :
500 mm
Air Pressure(MPa) :
0.7 MPa
Air Comsumption(m³/min) :
0.8 m³/min
Die Head Heating Power(kW) :
3 kW
Power (kW) :
79
Weight (T) :
15
Key Selling Points :
Long Service Life
Applicable Industries :
Energy & Mining, Hotels, Home Use, Machinery Repair Shops, Restaurant, Food & Beverage Factory, Farms
Showroom Location :
Egypt, Indonesia, Pakistan, Thailand, Chile, Algeria
Rotary Cylinder Brand :
FESTO
Station :
SIngle Station
Suitable bottle :
1-12L
Key words :
Extrusion Blow Moulding Machine
Packing :
Wooden
Use :
Hollow Moulding
Parison Control :
MOOG
Max. Size of Mold :
590*500
Description
TONGDA HS12L High Production Blowing Molding Machine Detergent Bottle Making Equipment
Product Description

This is our best series machine. This is hydraulic servo system. The clamping unit is elbow style and the clamping force is more uniform. It is high speed and energy-saving. This machine is suitable for PEHD jar / carboys / obilique neck, etc. It can be also equipped with several die-heads and then to make the small product.
Technical Parameters
MODEL
Units
HSII-12L
Remarks: The main parts of this machine are designed and manufactured by ourself.We do the independent R&D and inspection.If you have other special requirements,we can provide customized services for you.
Max. Product volume
L
12
Output of HDPE
kg/h
120
Clamping force
kn
158
Screw diametre
mm
80
Screw heating power
kw
19
Blow pressure
mpa
0.7
Size of machine
m
5.21x2.62x3.2
Product Details

CE Standard

Modularized components, easy replace

Digitizing and famous

PE PC Daily Chemical Bottle Blow Molding Machine / Detergent Bottle Making Machine

15 Inches

Color Control Screen

More Convenient Operation

PE PC Daily Chemical Bottle Blow Molding Machine / Detergent Bottle Making Machine

Company Information
Suzhou Tongda Machinery have more than 20,000m2 factory buildings and other facilicities and a new intelligent manufacturing factory with 55,000m2 area. The I phase 20,000m2 area factory will be put into use in June, 2022. And on May 19th, 2022, we just held the II phase intelligent manufacturing base groundbreaking ceremony.
PE PC Daily Chemical Bottle Blow Molding Machine / Detergent Bottle Making MachinePE PC Daily Chemical Bottle Blow Molding Machine / Detergent Bottle Making Machine

After-sales services

Tongda has a sound service network, perfect after-sales service system, 14 professional after-sales service teams across the country, and a timely response service mechanism to continuously improve user satisfaction. Serve every customer sincerely, respond quickly, and solve the problems raised by customers in a timely manner. We will regularly send debugging engineers to visit customers and solve problems in time.

PE PC Daily Chemical Bottle Blow Molding Machine / Detergent Bottle Making Machine

FAQ

Advantages of TONGDA after-sales team
1. Lifetime free service for the machine.
2. Quick response all day long.
3. Set up domestic service team and international service team.
4. Technicians also master the debugging and maintenance of auxiliary equipment.
5. A free 2-day training course will be provided to customers every year.
6. Special processing equipment to produce after-sales accessories to ensure rapid response to user needs.


Q: How big is your company?
A: our company has 400 employees and A building area of 100,000 square meters. We own land and factories.The company has a registered capital of us $2 million and a long-term business license since 1999.


Q: How long is the warranty on your equipment?
A: we offer A one-year free warranty and A lifetime after-sales service.
