Electric Hammer RD22U Shaft Seal 3115336500
Electric Hammer RD22U Shaft Seal 3115336500
Specifications
Place of Origin :
CHINA
Delivery Time :
15days
Applicable Media :
Gear oil, hydraulic oil, grease
Payment Terms :
T/T
MOQ :
1
Supply Ability :
9999
Brand Name :
Atlas Copco / Epiroc
Weight :
Approx. 0.1–0.2 kg
Price :
128
Packaging Details :
Original packaging
Temperature Range :
-20℃ ~ +100℃
Linear Speed :
≤ 8 m/s
Model Number :
3115336500
Pressure Resistance :
≤ 10 bar (for low-pressure lubrication / gearbox)
Description

Epiroc 3115336500 (RD22U Electric Hammer Shaft Seal)


1. Basic Information


Part No.: 3115336500

Name: Shaft Seal / Oil Seal

Brand: Epiroc (Formerly Atlas Copco)

Application Model: RD22U Electric Hammer. Also applied to the rotating and drive end sealing of small hydraulic rock drills in COP series.

Function: Prevent oil leakage, dust and slurry ingress at the main rotating shaft to protect bearings and internal gears.

Structure: Single-lip / Double-lip encapsulated oil seal with metal frame and rubber coating.

Weight: Approx. 0.1–0.2 kg

Alternative Names: Oil Seal, Rotary Shaft Seal

2. Technical Specifications


Material: NBR (Nitrile Butadiene Rubber) with steel frame

Applicable Shaft Diameter: Standard φ22 mm for RD22U main shaft

Pressure Resistance: ≤ 10 bar (for low-pressure lubrication / gearbox)

Temperature Range: -20℃ ~ +100℃

Linear Speed: ≤ 8 m/s

Applicable Media: Gear oil, hydraulic oil, grease

4. Installation Guidelines


Clean the shaft and housing thoroughly before installation to remove burrs and rust.

Install the seal with the lip facing the oil side (towards gearbox / oil chamber).

Press the outer ring in gently to avoid deformation; apply a small amount of grease on the seal lip.

Rotate the shaft manually after installation to ensure no jamming or abnormal wear.
