ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control
ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control
ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control
ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control
ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control
ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control
Specifications
Model Number :
ACS550-01-012A-4
Packing Size :
180 × 75 × 156 mm
Supply Ability :
99+
Brand Name :
ABB
Condition :
Brand new and original
Packaging Details :
Brand new and original
Payment Terms :
T/T,paypal,alipay
MOQ :
1 pc
Delivery Time :
3-5 days
Shipping Weight :
1.8 kg
Price :
$100
Express Delivery :
DHL, FedEx, UPS
Certification :
COO & COC
Trade Terms: :
EXW, DAP, FOB, CIF
Place of Origin :
Italy
Warranty :
One year
Description

ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control

The ABB ACS550-01-012A-4 is an original low voltage AC drive from the globally recognized ACS550 general-purpose series, delivering 5.5kW rated power at 11.9A continuous output current for three-phase 380-480V induction motor applications. Designed for both variable-torque loads such as pumps and fans and constant-torque loads including conveyors and mixers, this VFD inverter provides reliable open-loop scalar and sensorless vector speed regulation.
Equipped as standard with an integrated EMC filter, dual DC choke for harmonic suppression, built-in Modbus RTU communication interface, and an assistant control panel with startup wizards, the ACS550-01-012A-4 minimizes commissioning effort and eliminates the need for external filtering components.Installing a genuine ABB ACS550-01-012A-4 replaces degraded power modules and faulty control boards, restoring stable motor acceleration, accurate speed holding, and energy-saving performance without parameter reconfiguration.

Product Specifications: ABB ACS550-01-012A-4


Parameter Specification
Brand ABB
Part Number ACS550-01-012A-4
Product Type Low Voltage AC Drive / VFD Inverter
Series ACS550
Frame Size R1


Product Images


ACS550-01-012A-4 ABB Original Low Voltage AC Drive 5.5kW 11.9A VFD Frequency Inverter 380-480V Motor Speed Control

Related Products


ACS550-01-03A3-4 ACS550-01-04A1-4
ACS550-01-05A4-4 ACS550-01-06A9-4
ACS550-01-08A8-4 ACS550-01-015A-4
ACS550-01-023A-4 ACS550-01-031A-4
ACS550-01-038A-4 ACS550-01-044A-4
ACS550-01-059A-4 ACS550-01-072A-4
ACS550-01-087A-4 ACS550-01-124A-4
ACS550-01-157A-4 ACS550-01-180A-4
ACS550-01-012A-2 ACS550-01-015A-2
ACS550-01-025A-2 ACS550-01-038A-2


FAQ

Q1: What motor power does the ABB ACS550-01-012A-4 drive?
A: It controls three-phase 380-480V induction motors up to 5.5kW (normal duty) or 4kW (heavy duty).
Q2: Does the ACS550-01-012A-4 require an external EMC filter?
A: No. A Category C3 EMC filter and dual DC choke are integrated as standard, reducing installation cost and panel space.
Q3: Is the ABB ACS550-01-012A-4 supplied as an original unit?
A: Yes. We provide genuine ABB original drives, factory-tested for output waveform, insulation resistance, and Modbus communication integrity.
