LC Connector Media Converter with SFP Port and RJ45 for 80KM Fiber Distance Extension
LC Connector Media Converter with SFP Port and RJ45 for 80KM Fiber Distance Extension
LC Connector Media Converter with SFP Port and RJ45 for 80KM Fiber Distance Extension
LC Connector Media Converter with SFP Port and RJ45 for 80KM Fiber Distance Extension
Specifications
Brand Name :
GEZHI or OEM
Model Number :
GZ-MC-10/100BASESFP
Certification :
CE RoHS,ISO9001
Place of Origin :
China
MOQ :
1pc
Price :
Negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
5000pcs per month
Packaging Details :
Paper box
Data Rate :
10 / 100M auto-negotiation
Transmission Mode :
Full-duplex/semi duplex
Power Supply :
5V DC 1A or 110~265V AC 48V DC
Power Dissipation :
<2.5W
Operating Temperature :
0~60℃
Transmit Distance :
20/40/60/80/100/120Km (single mode)
Description

Netaxcess 10 / 100Base TX To 100Base FX Media Converter LC Connector With SFP Port / Rj45

DESCRIPTION

This series converters are designed to meet the massive needs for network deployment and able to extend a copper based network via fiber cable to a maximum distance up to 80KM.

This series converters are fully compliant with IEEE802.3z & 802.3ab standards. It can be installed into a Standard Converter Chassis. The installation & operation procedures are simple & straightforward. Operation status can be locally monitored through a set of Diagnostic LED located in the front panel.

FEATURERS

1.10/100Base-TX to 100BASE-FX Converter
2.Standard : IEEE 802.3z & 802.3ab
3.Interface: 1 x RJ-45 connector / 1 x SFP Slot
4.MDI/MDIX Auto-Crossover supported
5.LED: Power , DUP,FP-LINK,RX, ,TX
6.Plug-and-Play installation
7.Support Jumbo Frame (64-9216 Byte)
8.Support Voltage Monitor

Dimension

External power supply : 94 x 70.5 x 26.5 mm (W x D x H)
Internal power supply : 140.5 x 111 x 30 mm (W x D x H

LC Connector Media Converter with SFP Port and RJ45 for 80KM Fiber Distance Extension

LC Connector Media Converter with SFP Port and RJ45 for 80KM Fiber Distance Extension

Specifications

Item Specification/Term
1 Item number BT-950SFP series
2 Standard Protocol IEEE802.3u,10/100Base-T,100Base-SX/LX,IEEE802.3ah, IEEE802.3z/ab
3 Flow control IEEE802.3x port flow control and back pressure control
4 Transmission speed 10/100M auto-negotiation
5 Transmission mode Full-duplex/semi duplex(auto-negotiation)
6 Conversion mode Storage transmission
7 MAC address VLAN 4K
8 Buffer space 128KB
9 Packet length Storage transmission:9728Bytes,straight-through,infinite.
10 Time-delay 9.6us
11 Bit error rate <1/ 000000
12 MTBF 100,000 hours
13 Power supply Outside: 5V DC 1A ; Build-in: 110~265V AC 48V DC
14 Power dissipation <2.5W
15 Interface Electric port: RJ45,Fiber port:SC/FC or SFP
16 Twisted-pair cable Cat.5 UTP cable
17 Multimode fiber 50/125, 62.5/125um
18 Single mode fiber 9/125, 10/125um
19 Wavelength 850nm/1310nm/1550nm
20 Transmit distance
1)Dual fiber multimode 550m
2)dual fiber single mode 20/40/60/80/100/120Km
3)single fiber single mode 20/40/60/80Km
4)Cat.5 twisted-pair 100m
21 Operating temperature 0~60℃
22 Storage temperature -20~70℃
23 Humidity 5%~90% (no condensation)

SHIPMENT & DELIVERY

1.International Express: DHL, Fedex, UPS, EMS, UPS, TNT and etc.
2.Payment: T / T, Western Union, Paypal and so on.
3.Packing Details: Static bag, Plastic PVC Pack, Retail box, Technical box, or customized.

GUARANTEE

1. Brand new.
2.OEM/ODM is available.
3.100% through quality test and aging test.
4.3 years warranty(From the date of shipment)
