2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer
Specifications
Brand Name :
GEZHI or OEM
Model Number :
DWDM04MXXX
Certification :
CE RoHS,ISO9001
Place of Origin :
China
MOQ :
1pc
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000Channel per month
Delivery Time :
5-8 work days
Packaging Details :
Paper box
Product Name :
2CH DWDM
Channel Spacing :
20nm
Fiber type :
SMF-28e
Center Wavelength :
1270~1610nm
Channel Number :
4, 8, 16, 18 or Customized
Application :
Data Center
Description

Description of 2CH DWDM

2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer

DWDM

DWDM Module can solve the shortage of fiber resources and transparent transmission of business, and reduce the cost of network Construction. With low-cost and compact dimension, it is mainly used in metropolitan area network and access layer, also be used to build networks.

Features & Applications of 2CH DWDM

Features Applications

Low Insertion Loss

High Isolation
High Stability & Reliability
Industrial Operating Temperature
(-40~+80℃ available)
Customized Package type:
Stainless Steel tube, ABS Box, ABS Plug-in Module, LGX Chassis, Rackmount
 Line Monitoring
WDM Network
Telecommunication
DATA Center

Specifications of 2CH DWDM

Parameter
Unit
DWDM Mux Demux
Channel Spacing
nm
20nm
Center Wavelength
nm
1270~1610 or 1271~1611
Channel Passband
nm
±6.5
Channel Number
/
4CH
8CH
16CH
Insertion Loss
dB
<1.5
<2.5
<5.5 or <3.5(with skip)
Isolation @Adjacent Channel
dB
>30
Isolation @Non-adjacent Channel
dB
>40
Isolation @Express Port
dB
>15
Polarization Dependent Loss
dB
<0.2
Polarization Mode Dispersion
dB
<0.1
Directivity
dB
>50
Return Loss
dB
UPC >45 APC>50
Power Handling
mW
<500 (High Power type available)
Fiber Type
/
SMF-28e (Polarization Maintaining Type available)
Operating Temperature
℃
-20~+75 (-40~+85 available)
Storage Temperature
℃
-40~+85
Package Type
mm
ABS Box, ABS Plug-in Module, LGX Chassis, Rackmount

Similar Products

2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer 2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer 2CH Channel ABS Box DWDM Mux Demux Module Wavelength Division Multiplexer

8CH CWDM Mux Demux
ABS box LC/UPC pigtailed

 10Gbps DWDM transceiver
40km distance 		T1625nm Filter WDM
with SC/UPC connector

FAQ

Q1:Can I have a sample order? What is your MOQ of 2CH CWDM?

A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
Q2: What's the Lead time?
A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q3: What are the payment terms?
A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.
Q4: What is your warranty time?
A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
