Hitachi MOLDINO JDMT150508R PTH30E Carbide Milling Insert with FW Chipbreaker and 0.8mm Corner Radius for CNC Machining
Hitachi MOLDINO JDMT150508R PTH30E Carbide Milling Insert with FW Chipbreaker and 0.8mm Corner Radius for CNC Machining
Hitachi MOLDINO JDMT150508R PTH30E Carbide Milling Insert with FW Chipbreaker and 0.8mm Corner Radius for CNC Machining
Hitachi MOLDINO JDMT150508R PTH30E Carbide Milling Insert with FW Chipbreaker and 0.8mm Corner Radius for CNC Machining
Specifications
Model Number :
JDMT150508R PTH30E
Overall Length :
90 mm
Brand Name :
Hitachi
Shank Diameter Range :
3 mm to 25 mm
Price :
2-10usd/pcs
Tip Height :
3.55
Packaging Details :
Carton with Bubble paper which is suitable for long-distance transport
Radius :
R10 mm
MOQ :
100
Hardness :
Up to 1600 HV
Delivery Time :
4weeks
Operating Temperature :
Up to 800°C
Description
Original Japan Hitachi MOLDINO JDMT150508R PTH30E R0.8 FW Chipbreaker Milling Insert for Mold & Auto Machining Cutting tools CNC tools

Hitachi MOLDINO JDMT150508R PTH30E Carbide Milling Insert with FW Chipbreaker and 0.8mm Corner Radius for CNC Machining



Product Overview

The Hitachi JDMT150508R PTH30E is a high-performance positive rake indexable carbide milling insert manufactured by Hitachi Tool (MOLDINO, Japan). This double-sided 2-corner milling insert adopts special FW chipbreaker geometry paired with PTH30E exclusive multi-layer TH coating, designed for high-efficiency shoulder milling, face milling and contour profiling on carbon steel, alloy steel, stainless steel and titanium alloys. It features 0.8mm corner radius, stable anti-wear and anti-built-up-edge performance, perfectly matched with Hitachi AHJ/AJX series shoulder milling cutter bodies for mold and automotive batch CNC machining.

Key Features
  • Brand: Hitachi (MOLDINO, Japan professional metal cutting tool brand)
  • Full Model Code: JDMT150508R PTH30E
  • Insert Shape: Positive rake double-sided 2-cutter-corner milling insert
  • Size Specification: Side length 16mm, width 9.12mm, thickness 5mm
  • Corner Radius (RE): 0.8 mm
  • Chipbreaker Type: FW general-purpose chipbreaker
  • Coating Grade: PTH30E (TH series multi-layer hard anti-adhesion coating)
  • Coating Appearance: Bronze reddish finish
  • Number of Usable Edges: 2 cutting corners
  • Relief Angle: D-type 15° positive back relief angle
  • Matched Cutter Body: Hitachi AHJ, AJX series square shoulder milling end mills
  • Recommended Clamping Screw: Hitachi dedicated Torx insert locking screw for JDMT series
  • Standard Packing: 10 pieces per original plastic compartment box
Technical Specifications
Item Parameter
Complete Part Number JDMT150508R PTH30E
Insert Form Code JDMT (Shoulder Milling Double Corner Insert Series)
Side Length 16 mm
Insert Thickness 5 mm
Cutting Corner Radius R0.8 mm
Chipbreaker Style FW Multi-purpose chip control groove
Coating Grade PTH30E TH composite wear-resistant coating
Relief Angle 15° Positive rake angle
Usable Cutting Corners 2 pcs double-sided edges
Compatible Tool Holders Hitachi AHJ / AJX series indexable milling cutter bodies
Processing Hole Type Through holes & shallow blind holes
Max Machinable Hardness ≤ HRC 42
Standard Package Quantity 10 pcs / plastic box
Origin Made in Japan
Applicable Workpiece Materials
  • Carbon steel: 1018, 1045, A3 mild steel
  • Alloy structural steel: 40Cr, 4140, pre-hardened mold steel P20 / 718H
  • Stainless steel: 304, 316, duplex stainless steel
  • Titanium alloy, heat-resistant superalloy
  • Grey cast iron & ductile iron
Typical Applications
  • High-efficiency square shoulder side milling for mold bases, plastic molds
  • Step surface roughing & semi-finishing on automotive structural parts
  • Contour profiling, cavity shallow slot milling on CNC machining centers
  • Hydraulic fittings, mechanical general component batch mass production
  • Wet coolant high-speed milling requiring long tool service life
Advantages of Hitachi JDMT150508R PTH30E Milling Insert
  • PTH30E multi-layer TH coating: Ultra-low friction coefficient effectively suppresses chip adhesion and built-up edge, greatly improves wear resistance when processing sticky stainless steel & titanium alloy
  • FW optimized chipbreaker: Balanced chip curling performance for both rough and semi-finish milling, prevents long strip chips tangling around cutters
  • Double-sided 2 usable corners: Double service life compared to single-edge inserts, reduces overall tool cost
  • 15° positive rake design: Low cutting resistance, lowers machine spindle load and reduces machining vibration
  • Original Japanese ultra-fine grain carbide substrate: Excellent toughness to resist edge chipping under interrupted cutting
  • Universal matching compatibility: Fully interchangeable with all standard Hitachi AHJ/AJX series shoulder milling cutters
