PVD Coated Double-Sided Carbide Insert for Heavy-Duty Steel Milling CNC Milling Tool
PVD Coated Double-Sided Carbide Insert for Heavy-Duty Steel Milling CNC Milling Tool
PVD Coated Double-Sided Carbide Insert for Heavy-Duty Steel Milling CNC Milling Tool
PVD Coated Double-Sided Carbide Insert for Heavy-Duty Steel Milling CNC Milling Tool
PVD Coated Double-Sided Carbide Insert for Heavy-Duty Steel Milling CNC Milling Tool
PVD Coated Double-Sided Carbide Insert for Heavy-Duty Steel Milling CNC Milling Tool
Specifications
Density :
14.89
Delivery Time :
4 weeks
Tip Height :
3.55
Model Number :
SNMU120612GM GA4230
Brand Name :
GESAC
Feed Per Revolution :
0.35mm/r(0.25~0.7)
Fixed Pitch :
2.5mm ISO Pitch
Thickness :
2.38 mm
Packaging Details :
Carton with Bubble paper which is suitable for long-distance transport
Thread Pitch :
11 TPI Whitworth
Price :
2-10USD/PCS
Payment Terms :
T/T
MOQ :
100
Description
SNMU120612GM GA4230 GESAC PVD Insert for Heavy-Duty Steel Milling

PVD Coated Double-Sided Carbide Insert for Heavy-Duty Steel Milling CNC Milling Tool

Product Overview

The GESAC SNMU120612GM GA4230 is a high-performance double-sided square indexable carbide milling insert from GESAC (Xiamen Golden Egret Special Alloy Co., Ltd.) – a leading Chinese manufacturer of premium tungsten carbide cutting tools. Designed for heavy roughing to semi-finishing of steels, stainless steels, cast irons, and high-hardness materials (up to HRC 55), it features a GM chipbreaker and robust GA4230 PVD coating for exceptional impact resistance, chip control, and long tool life in demanding CNC milling applications.

Key Features
  • Model: SNMU120612GM GA4230
  • Brand: GESAC (Xiamen Golden Egret, China)
  • Geometry: SNMU = Square, double-sided, 4 usable edges, negative rake angle
  • Dimensions: 12 = IC 12.7 mm; 06 = thickness 6.35 mm; 12 = corner radius 1.2 mm
  • Chipbreaker: GM – optimized for heavy cutting, large chip space, efficient evacuation
  • Grade: GA4230 – high-strength ultrafine carbide substrate with PVD coating
  • Coating: Advanced PVD coating, excellent heat, wear, and adhesion resistance
  • Edges: 4 usable cutting edges (double-sided design), high rigidity for interrupted cuts
Workpiece Materials
  • Carbon steels (P20–P40) – primary
  • Stainless steels (M20–M30, 304/316/420)
  • Alloy steels (4140, 42CrMo4, HRC < 55)
  • Grey & ductile cast irons (K10–K30)
  • Hardened steels (HRC 50–55)
Typical Applications
  • Heavy face milling & shoulder milling
  • High-feed milling & roughing (large depth of cut)
  • Slotting, ramping, and profiling (interrupted cuts)
  • General-purpose CNC milling (mass production & heavy job shops)
  • Dry machining (excellent thermal stability)
Technical Specifications
Item Parameter
Model GESAC SNMU120612GM GA4230
Product Type Indexable Carbide Milling Insert
Shape Square (Double-sided, 90° cutting edge)
Relief Angle Negative (high rigidity)
Inscribed Circle (IC) 12.7 mm (0.5 in)
Thickness (S) 6.35 mm (0.25 in)
Corner Radius (Re) 1.2 mm (0.047 in)
Chipbreaker GM (Heavy-Duty Milling)
Grade GA4230 (PVD Coated Ultrafine Carbide)
Coating PVD (Heat & Wear Resistant)
Usable Edges 4 (Double-sided)
Compatible Holders 45°/75° shell mill cutters (NAC series)
Country of Origin China (Xiamen)
Packaging 10 pieces per box
Why Choose GESAC SNMU120612GM GA4230?

Combines a heavy-duty GM chipbreaker with GESAC’s durable GA4230 PVD grade. Delivers superior impact resistance, reliable chip control, and extended tool life in heavy roughing and high-hardness material milling. Ideal for shops seeking cost-effective, high-performance inserts for demanding CNC applications.
