Specifications
Model Number :
TGF32L100 LF6018
Tolerance :
±0.02 mm width
Packaging Details :
Carton with Bubble paper which is suitable for long-distance transport
Delivery Time :
4 weeks
MOQ :
100
Price :
2-10USD/PCS
Overall Height :
3.2 mm
Nose Radius :
R0.4mm
Payment Terms :
T/T
Groove Width :
1.0 mm
Coating Type :
PVD (Ti,Al)N
Brand Name :
DESKAR
Relief Angle :
Positive (~5°)
Description

TGF32L100 LF6018 Deskar 1.0mm Vertical-Clamp Grooving Insert for CNC Lathe

DESKAR TGF32L100 LF6018 PVD-Coated 1.0mm Vertical-Clamp Grooving Insert for CNC Lathe Precision Shallow Grooving Carbide end mills CNC tools

Product Overview

The DESKAR TGF32L100 LF6018 is a left-hand, vertical-clamp (TGF32 series) carbide grooving insert, specialized for precision shallow grooving, snap-ring (retaining ring) grooves, and light cutoff on CNC lathes and Swiss-type machines. Designed for 1.0 mm width grooves, it features a sharp, stable cutting edge and LF6018 PVD-coated grade, delivering low vibration, accurate groove dimension, and good surface finish in steels and stainless steels. Ideal for high-volume production of small-to-medium parts requiring narrow, shallow grooves.

Key Features
  • Vertical-Clamp (TGF32) Design: Rigid vertical mounting, excellent stability in grooving; reduces chatter in light cuts.
  • Left-Hand (L) Orientation: For left-side grooving; compatible with standard TGF32L tool holders.
  • 1.0 mm Groove Width: Precision ground width (±0.02 mm); perfect for standard snap-ring grooves.
  • LF6018 Grade: PVD (Ti,Al)N coating; good wear resistance and oxidation stability for P/M materials.
  • Sharp Positive Rake: Low cutting force, ideal for small machines and thin-walled parts.
  • Compact & Durable: Sintered carbide substrate with high hardness; resists chipping in interrupted cuts.
Workpiece Materials
  • Carbon steels (1045, S355, Q235)
  • Alloy steels (4140, 42CrMo4, HRC <38)
  • Stainless steels (304, 316, 420)
  • Low-carbon steels (1018, 1020)
  • Non-ferrous metals (aluminum, brass, light cuts)
Typical Applications
  • External shallow grooving (width = 1.0 mm)
  • Snap-ring / retaining ring groove turning
  • Light cutoff (small diameter bars, ≤20 mm)
  • Swiss-type CNC lathes & turning centers
  • Automotive, hydraulic, medical, and general engineering parts
  • Continuous or light interrupted grooving
  • High-precision mass production
Technical Specifications
Item Parameter
Model DESKAR TGF32L100 LF6018
Product Type Carbide Grooving / Snap-Ring Insert
Series TGF32 (Vertical-Clamp Shallow Groove)
Hand Left (L)
Groove Width 1.0 mm
Overall Height 3.2 mm
Mounting Vertical screw-on (TGF32 tool holder)
Grade LF6018 (PVD (Ti,Al)N Coated)
Coating Color Bronze-Gold
Relief Angle Positive (~5°)
Tolerance Precision ground (±0.02 mm width)
ISO Range P15–P30, M15–M25
Why Choose DESKAR TGF32L100 LF6018?

As a specialized 1.0 mm shallow grooving insert, it offers excellent dimensional accuracy and stability for snap-ring grooves. The LF6018 coating balances wear resistance and edge sharpness, while the vertical-clamp design minimizes vibration. It is a cost-effective solution for high-volume precision grooving in steels and stainless steels.
