Specifications
Substrate Material :
Fine-Grain Tungsten Carbide
Brand Name :
YG-1
Price :
2-10USD/PCS
Nose Radius :
R0.4mm
Grade :
YBM253
Cutting Diameter :
17 mm
Feed Rate :
0.35mm/r(0.25~0.7)
Tolerance :
±0.01mm
Item No :
CCMT
Cutting Edge Radius :
0.4 mm
MOQ :
100
Delivery Time :
4 weeks
Chipbreaker :
G2
Machining Stability :
High stability
Package Type :
Plastic box packaging
Usagelife :
Long-lasting, depends on application
Helix Angle :
38°
Payment Terms :
T/T
Fixed Pitch :
3.0mm ISO Pitch
Packaging Details :
Carton with Bubble paper which is suitable for long-distance transport
Hardness :
Up to 90 HRA
Model Number :
M1.6×0.35 YH1SF
Description

YH1SF YG-1 M1.6×0.35 Cobalt HSS-E Tap for Electronics Threading

YH1SF YG-1 M1.6×0.35 Cobalt HSS-E Tap for Electronics Threading Threading tools CNC cutting tools



Product Overview

The YG-1 M1.6×0.35 YH1SF is a high-precision miniature metric tap from YG-1 (South Korea), designed for tapping tiny M1.6×0.35 internal threads in precision electronics, medical devices, and small mechanical components. The YH1SF denotes YG-1’s proprietary YH1 precision limit and special flute geometry, ensuring accurate thread forming, reliable chip evacuation, and long tool life in small-diameter threading.

Key Features
  • Brand: YG-1 (South Korea, global cutting tool manufacturer)
  • Model: M1.6×0.35 YH1SF
  • Tool Type: Miniature Metric Thread Tap (Straight/Spiral Flute)
  • Thread Specification: M1.6 (Major Dia 1.6 mm) × 0.35 mm Pitch
  • Precision Class: YH1 (YG-1’s proprietary precision for fine threads)
  • Material: HSS-E (Cobalt High-Speed Steel) for heat & wear resistance
  • Coating: Bright/Uncoated or TiN (optional, for friction reduction)
  • Flutes: 2–3 flutes (optimized for small chips, stable cutting)
  • Chamfer: Plug (2–3P) for general through/blind hole tapping
  • Shank: Miniature cylindrical shank for precision holders
  • Direction: Right-hand thread (standard)
Technical Specifications
Item Parameter
Full Model M1.6×0.35 YH1SF
Brand YG-1 (South Korea)
Thread Size M1.6×0.35 mm
Precision YH1 (YG-1 fine thread limit)
Material HSS-E (Cobalt High-Speed Steel)
Coating Bright / TiN (optional)
Overall Length 40–41 mm
Thread Length 7–8 mm
Shank Diameter 2.5 mm
Flute Count 2
Tap Drill Size 1.25 mm (recommended)
Workpiece Hardness Up to HRC 40
Origin Made in South Korea
Packaging 1 piece per plastic tube
Workpiece Materials
  • Carbon steels (1015, S15C) – primary
  • Alloy steels (4140, HRC < 40)
  • Stainless steels (304, 316L, soft)
  • Brass & copper (easy chip evacuation)
  • Aluminum alloys (light cuts, polished flutes)
  • Grey cast iron (HT150, low speed)
Typical Applications
  • Miniature internal thread tapping (M1.6×0.35) in CNC precision centers
  • Electronics, medical devices, watches, and small molds
  • Through-hole & shallow blind-hole threading
  • Mass production of micro-components requiring YH1 precision
  • Dry or minimal coolant for small-diameter stability
  • Finishing operations for smooth thread surface
Why Choose YG-1 M1.6×0.35 YH1SF?
  • YH1 precision: Tight tolerance for perfect fit in miniature assemblies
  • HSS-E grade: Withstands high temperatures in small-diameter cutting
  • Special flute (SF): Optimized chip geometry prevents clogging in tiny holes
  • YG-1 quality: Korean manufacturing, consistent performance in mass production
  • Miniature design: Ideal for hard-to-reach, small-part threading
