Express Guardrail Post Forming Machine, C U Profile machine
Express Guardrail Post Forming Machine, C U Profile machine
Specifications
Place of Origin :
China
Brand Name :
Jack-Aiva
MOQ :
Negotiable
Price :
Negotiable
Delivery Time :
70 working days
Payment Terms :
T/T L/C
Certification :
CE SGS
Name :
Express guardrail C U Profiles Machine
Line structure :
Portal-type frame style: 45# steel
Raw material thickness (MAX.) :
3.5mm – 6mm
Driving mode :
WITH CARDAN SHAFT, 140*400
Forming Roller Stations:Forming Roller shaft: ¢100mm, 45#, treating :
15 Stations
Control mode :
PLC
Description

Express guardrail C U Profiles Machine

Express Guardrail Post Forming Machine, C U Profile machine

C channel highway safety used guardrail post

C profile & U profile are as the important members of highway barriers system used as guardrail connection and post, etc.

The roll-formed galvanized profiles feature the latest advancements in highway safety barrier technology. Galvanized guardrails profiles are coated with a uniform layer of zinc coating to prevent discoloration and weak spots caused by rust and corrosion.

Express guardrail C & U profiles roll forming machine technology specifications

We special designed the roll forming machine, C profiles & U profiles can produced by the same roll forming machine to reduce the investment. This forming machine mainly consists of de-coiler, guide equipment, leveling system, punching, roll forming system, cutting system, etc.

C U Profile Rail Forming machine main parameters

Raw material thickness (MAX.) C U PROFILE
Line structure Portal-type frame style: 45# steel
Raw material thickness (MAX.) 3.5mm – 6mm
Forming Roller Stations: 15 Stations (7 rolls leveling)
Forming Roller shaft: ¢140mm, 45#, treating
Forming rollers GCr15, quenching, hardness HRC56-62º
Forming Speed: 12 meters / min (suggestion speed: 7-8m/min)
Main motor: 60kw
feed material thickness: (2-5) mm× L
Suitable raw material: Q235A galvanized steel sheet
Driving mode: WITH CARDAN SHAFT, 140*400
Cutting mode: automatic punching cutting style
Blade material: Cr12, quenching and treating
Control mode PLC

Expressway guardrail C & U profile

We offer Innovation and Design of complete roll forming machine for the Highway industry, including installation and world class service. We are a global supplier of Rollforming Systems with a Local presence. We specialize in roll former machines engineered to produce expressway 2 – space W beam guardrails, Guardrail sigma posts, corrugated steel beam, Sign posts, highway Barriers, steel guardrail cross beam, Guardrail End, etc. . The custom express high way guardrail profile is welcome!
