ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
Specifications
Formability :
Good
Outside Diameter :
10-500mm
Uns :
S31254
Specification :
Any Size Can be Customised
Materialcomposition :
Copper-Nickel Alloy (commonly 90/10 or 70/30 Cu/Ni ratio)
Product name :
ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube
Price Term :
CIF CFR FOB Ex-Work, CIF, CFR, FOB, CNF
Outer Diameter :
6MM-419.1MM
Productname :
Copper Nickel Pipe
Grade :
90/10 Copper Nickel Alloy C70600
Size :
1/2
Surface Treatment :
Polished
Connection :
Welding
Model :
A182 F53
Supply Ability :
10Ton/Month
Delivery Time :
15-30 Workdays
Model Number :
Copper Nickel Pipe
Certification :
ISO/TUV/SGS
Price :
Negotiable
Payment Terms :
T/T, Western Union
Color :
Copper Color
Feature :
Good thermal
Pressurerating :
Up to 1500 psi depending on specification
Elongation :
Good
Packaging Details :
Standard Shipping Package
Shape :
Pipe
Dia :
3mm-800mm/custom
Surface :
Smooth
Durability :
High
Alloy Or Not :
Non-Alloy
Brand Name :
TOBO
Place of Origin :
Shanghai,China
MOQ :
1PC
Packing :
Pallet, Wooden Case
Corrosion Resistance :
High
Type :
Seamless Pipe / Welded pipe
Form :
Pipe
Machinability :
Good
Package :
Standard package.Ten pieces per carton.
Description

ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube

1.Product Description

Copper nickel pipe is a high-performance alloy tube primarily composed of copper with nickel as the principal alloying element. It is manufactured in accordance with international standards such as ASTM B466/B467, BS 2871, and DNV. The two most common grades are C70600 (90/10) and C71500 (70/30). This material is specifically engineered for demanding environments requiring excellent resistance to seawater corrosion, thermal conductivity, and good mechanical strength.

2.Product Applications

  • Marine & Shipbuilding: Seawater cooling lines, ballast systems, fire main systems, sanitary piping.

  • Offshore & Oil & Gas: Hydraulic and lubrication lines on platforms, fire water systems.

  • Power Generation: Steam turbine condensers, feedwater heaters, air coolers (nuclear & thermal plants).

  • Desalination: Multi-stage flash (MSF) and reverse osmosis (RO) evaporator tubing.

  • Chemical Processing: Heat exchangers for acetic acid, brine, and other mild corrosive media.

​3.Product Advantages

  • Superior Seawater Corrosion Resistance: Excellent resistance to pitting, crevice corrosion, and stress corrosion cracking (SCC) in chloride environments.

  • Anti-Biofouling: Natural resistance to marine organism attachment, reducing maintenance and flow blockage.

  • High Erosion Resistance: Performs well in high-velocity seawater (3.5 – 4.5 m/s), resisting impingement attack.

  • Excellent Fabricability: Can be easily bent, expanded, flanged, and welded using standard techniques.

  • Proven Longevity: Service life of 30+ years in marine applications, offering low life-cycle cost.

  • Good Thermal Conductivity: Higher than stainless steel, making it ideal for heat transfer equipment.

​ASTM B151 Copper Nickel Pipe CuNi 70/30 Boiler & Condenser Seamless Tube

​4.Key Product Parameters

Parameter C70600 (90/10) C71500 (70/30)
Nickel Content (%) 9.0 – 11.0 29.0 – 33.0
Iron Content (%) 1.0 – 1.8 0.4 – 1.0
Manganese Content (%) ≤ 1.0 ≤ 1.0
Outer Diameter Range 6 mm – 610 mm 6 mm – 610 mm
Wall Thickness Range 0.5 mm – 50 mm 0.5 mm – 50 mm
Length Random (3–12 m) or Fixed Random (3–12 m) or Fixed
Density (20°C) 8.90 g/cm³ 8.94 g/cm³
Melting Range 1100 – 1240 °C 1170 – 1240 °C
Tensile Strength (min.) 310 MPa 480 MPa
Yield Strength (0.2% offset, min.) 110 MPa 170 MPa
Elongation (min.) 30% 25%
Thermal Conductivity (20°C) 40 W/(m·K) 29 W/(m·K)
Coefficient of Thermal Expansion (20-300°C) 17.0 × 10⁻⁶ /K 16.2 × 10⁻⁶ /K
Electrical Resistivity 0.19 µΩ·m 0.38 µΩ·m
Hardness (HB max.) 90 125

FAQ

1. Are you trading company or manufacturer ?
We are manufacturer ,You can see the certification.
2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
