High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
Specifications
Joiningmethod :
Butt weld or socket weld
Payment Term :
T/T, L/C, etc.
Product name :
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
Size :
3/4
Paking :
wooden case
Standards :
ASTM B466, ASTM B111, ASTM B164
Brand Name :
TOBO
Wallthickness :
Schedule 10, 40, 80
Customized :
Customized support
Supply Ability :
10Ton/Month
MOQ :
1PC
Delivery Time :
15-30 Workdays
Packing :
Standard Seaworthy Package
Certification :
ISO/TUV/SGS
Temperature Level :
High Temperature
Payment Terms :
T/T, Western Union
Head Type :
Round
Price :
Negotiable
Surface Finish :
Polished
End Connection :
Butt Weld, Socket Weld, Threaded
Temperature :
High
Model Number :
Copper Nickel Elbow
Packaging Details :
Standard Shipping Package
Pressure :
High
Place of Origin :
Shanghai,China
Manufacturing Process :
Push, Press, Forge, Cast,
Description

High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9

1. Product Description

Copper nickel elbow is manufactured from copper-nickel alloy (CuNi), common grades C70600 (90/10) and C71500 (70/30). It offers excellent seawater corrosion resistance, anti-fouling properties, and good weldability, suitable for corrosive media piping systems.

2.Product Applications

Mainly used in shipbuilding, marine engineering, desalination, power industry, and petrochemical piping systems, especially for seawater, cooling water, and corrosive chemical media.

​3.Product Precautions

  • Avoid direct contact with dissimilar metals such as carbon steel to prevent galvanic corrosion

  • Control interpass temperature ≤100℃ during welding, use matching welding wire

  • Store in dry, well-ventilated environment, keep away from acids, alkalis, and acetylene gas

​High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9

​4.Key Parameters

Parameter Value
Material Grades C70600 (90/10), C71500 (70/30)
Size Range DN6 ~ DN600 (1/4″ ~ 24″)
Angle Options 45°, 90°, 180° (other angles available)
Bend Radius Long radius R=1.5D, Short radius R=1.0D
Pressure Rating 150LB, 300LB, 600LB / PN10 ~ PN40
Operating Temperature -29℃ ~ +260℃
Applicable Standards ASME B16.9, DIN 86090, GB/T 12459

FAQ

1. Are you trading company or manufacturer ?
We are manufacturer ,You can see the certification.
2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
