YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
Specifications
Brand Name :
YUNNEI
Model Number :
YUNNEIYN25ANJ21
Place of Origin :
China
MOQ :
1
Price :
USD 300-860
Payment Terms :
L/C, T/T, D/P
Supply Ability :
500PCS Per Month
Delivery Time :
30 work days
Packaging Details :
200*85*105cm
Description
YUNNEI Diesel Generator
YUNNEI Diesel Generator Set. Our YUNNEI YN25ANJ21 Diesel Generator is a high-performance, heavy-duty diesel generator set designed for reliable prime and standby power. Engineered with the renowned YUNNEI engine, this 18kW unit is encased in a robust soundproof canopy, making it an ideal solution for applications requiring low noise operation without compromising on power and durability. It is the perfect power source for construction, industrial, commercial, and emergency backup use.

YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime PowerYUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power

General information Prime power Standby power
Rated Power (kVA) 23 25
Power Rating (kW) 18 20
Frequency (Hz) 50
Engine Model YN25ANJ21
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated voltage (V) 400/230
(According to customer requirements)
Fuel tank capacity operating time ≥ 8h @ 75% load
PRP ●Prime power is available for an unlimited number of annual hours in variable load application,in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation
ESP ●The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption.No overload,utility parallel or negotiated outage operation capability is available at this ratin

Dimension and Weight
Model BYN25
Open type		 BYN25S
Silent type
Length (L) mm 1400 2000
Width (W) mm 610 850
Height (H) mm 1150 1050
Tank capacity (L) 41 41
Engine Specifications
Engine model & manufacturer YN25ANJ21(YUNNEI)
Engine model YN25ANJ21
Engine Rated Speed (rpm) 1500
Generator set Frequency(Hz) 50
Engine Prime Power (PRP)(kW) 21
Length (L) mm 900
Width (W) mm 540
Height (H) mm 760
Engine Dry Weight w/o Cooling System (kg) 200
Aspiration Type Nature
Injection Type Direct
Configuration Vertical
No. of Cylinders 4
Displacement(liters) 2.54
Bore(mm) 90
Stroke(mm) 100
Compression Ratio 17.5
Piston Speed (m/s) 5.0/6.0
Rotation Direction (from flywheel) Anti-clockwise
Number of Flywheel Teeth 109
Flywheel House Size SAE4
Alternator Specifications
Alternator
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-184E
Alternator Rated Power 18kw/23kva
Rated voltage (V) 230v/400v
Rated frequency 50hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%～+20%
Control Panel
DSE 6120
Auto start and auto mains failure control module(Alternator frequency & can speed sensing)
Key benefits
•Automatically transfers betweenmains (utility) and generator
(DSE6120 MKIII only) forconvenience.
•Hours counter provides accurateinformation for monitoring andmaintenance periods
•User-friendly set-up and buttonlayout for ease of use
•Multiple parameters are monitored& displayed simultaneously for fullvisibility
•The module can be configured tosuit a wide range of applications foruser flexibility
•PLC editor allows user configurablefunctions to meet user specificapplication requirements.
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
Key features
•4-line back-lit LCD text display
•Multiple display languages
•Five-key menu navigation
•LCD alarm indication
•Customisable power-up text andscreen images.
•DSENet® expansion compatibility
•Data logging facility
•Internal PLC editor
•Protections disable feature
•Fully configurable via PC using
USB communications
•Front panel configuration withPIN protection
•Power save mode
•3-phase generator sensing andprotection
•3-phase mains (utility) sensing andprotection (DSE6120 MKIII only)
•Automatic load transfer control(DSE6120 MKIII only)
•Generator current and powermonitoring (kW, kvar, kVA, pf)
•Mains (utility) current and power
monitoring (kW
, kvar, kVA, pf)(DSE6120 MKIII only)
•kW overload alarm
•Over current protection
•Breaker control via fascia buttons
•Fuel and start outputs configurablewhen using CAN
•6 configurable DC outputs
•4 configurable analogue/digitalinputs
•Support for 0 V to 10 V & 4 mA to20 mA sensors
•8 configurable digital inputs
•CAN, MPU and alternatorfrequency speed sensing in onevariant
•Real time clock
•Manual and automatic fuel pumpcontrol
•Engine pre-heat and post-heatfunctions
•Engine run-time scheduler
•Engine idle control for starting &stopping
•Fuel level alarms
•3 configurable maintenance alarms
•Compatible with a wide range ofCAN engines, including Tier 4engine support
•Uses DSE Configuration Suite PC
Softwar
e for simplifiedconfiguration
•Licence-free PC software
•IP65 rating (with optional gasket)offers increased resistance to wateringress
•Configurable CAN read &transmitted information.
•1 alternative configuration
Options
Engine Alternator Fuel System
Water Jacket Preheater PMG excitation 12 / 24 hour base tank
Oil Preheater Space heater Bunded fuel tank
Oil manual pump Winding temperature measuring External fuel tank
Automatic fuel feeding
Switch between external tank and base tank (three-way valve)
YUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime PowerYUNNEI YN25ANJ21 18kW Open Type Diesel Genset Prime Power
