Specifications
Brand Name :
FAWDE
Model Number :
P126TI-II
Place of Origin :
China
MOQ :
1
Price :
USD 18000-20000
Payment Terms :
L/C, T/T, D/P
Supply Ability :
500PCS Per Month
Delivery Time :
30 work days
Packaging Details :
390*140*195cm
Description
Industrial 250Kw DOOSAN Diesel Generator Set
High-performance heavy-duty diesel generator set with brushless alternator, silent type open frame, 50/60Hz ATS compatibility. Designed for reliable prime and standby power applications.
Product Overview
Our DOOSAN P126TI-II Diesel Generator is engineered with the renowned DOOSAN engine, delivering 250kw of power encased in a robust soundproof canopy. Ideal for applications requiring low noise operation without compromising on power and durability. Perfect for construction, industrial, commercial, and emergency backup use.
Industrial 250Kw DOOSAN Diesel Generator Set with Brushless Alternator Silent Type Open Frame 50/60Hz ATS Industrial 250Kw DOOSAN Diesel Generator Set with Brushless Alternator Silent Type Open Frame 50/60Hz ATS
Power Specifications
Specification Prime Power Standby Power
Rated Power (kVA) 313 344
Power Rating (kW) 250 275
Frequency (Hz) 50
Engine Model P126TI-II
Engine Speed (RPM) 1500
Phase 3
Power Factor (PF) 0.8
Control System Digital
Rated Voltage (V) 400/230 (customizable)
Fuel Tank Capacity Operating Time ≥ 8 hours @ 75% load
Dimensions and Weight
Model BDO344 (Open Type) BDO344S (Silent Type)
Length (L) mm 3100 3900
Width (W) mm 1050 1400
Height (H) mm 2100 1950
Tank Capacity (L) 575 575
Engine Specifications
Engine Model & Manufacturer P126TI-II (DOOSAN)
Engine Type Diesel, water cooled, Turbo charged & intercooled
Bore x Stroke 123 × 155mm
Displacement 11 liters
Cylinders and Arrangement Cast iron, 6 cylinder, In-line Type
Battery Charging Alternator 28.5V × 45A alternator
Starting Voltage 24V
Fuel System Mechanical Injection Pump
Fuel Filter Full flow, cartridge type with water drain valve
Lube Oil Filter Type Full flow, cartridge type
Lube Oil Capacity Max. 23 liters, Min. 20 liters
Flywheel Dimensions Clutch No. 14 M
Dry Weight 950kg (engine only)
Dimension (L×W×H) 1389 × 1389 × 1216 mm
Alternator Specifications
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-314DS
Alternator Rated Power 250kw/313kva
Rated Voltage (V) 230v/400v
Rated Frequency 50hz
Connecting Type 3 Phase and 4 Wire
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%~+20%
Control Panel - DSE 6120
Auto start and auto mains failure control module with alternator frequency & CAN speed sensing.
Key Benefits
  • Automatically transfers between mains (utility) and generator
  • Hours counter for accurate monitoring and maintenance periods
  • User-friendly set-up and button layout for ease of use
  • Multiple parameters monitored & displayed simultaneously
  • Configurable to suit wide range of applications
  • PLC editor allows user configurable functions
Industrial 250Kw DOOSAN Diesel Generator Set with Brushless Alternator Silent Type Open Frame 50/60Hz ATS
Key Features
  • 4-line back-lit LCD text display with multiple languages
  • Five-key menu navigation with LCD alarm indication
  • Customizable power-up text and screen images
  • DSENet® expansion compatibility with data logging facility
  • Internal PLC editor with protections disable feature
  • Fully configurable via PC using USB communications
  • 3-phase generator sensing and protection
  • 3-phase mains sensing and protection
  • Automatic load transfer control
  • Generator current and power monitoring (kW, kvar, kVA, pf)
  • Mains current and power monitoring
  • kW overload alarm and over current protection
  • Breaker control via fascia buttons
  • Fuel and start outputs configurable when using CAN
  • 6 configurable DC outputs and 4 configurable analogue/digital inputs
  • Support for 0V to 10V & 4mA to 20mA sensors
  • 8 configurable digital inputs
  • Real time clock with engine pre-heat and post-heat functions
  • Engine run-time scheduler with idle control
  • Fuel level alarms and 3 configurable maintenance alarms
  • Compatible with wide range of CAN engines including Tier 4
  • IP65 rating (with optional gasket) for water resistance
Available Options
Engine Alternator Fuel System Generating Set
Water Jacket Preheater PMG excitation 12/24 hour base tank Deepsea, ComAp, Smartgen controllers
Oil Preheater Space heater Bunded fuel tank Trailer
Oil manual pump Winding temperature measuring External fuel tank Tools with the machine
Automatic fuel feeding
Switch between external tank and base tank
