Specifications
Brand Name :
WEICHAI
Model Number :
6M33D633E200
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1
Price :
15000-19000USD
Supply Ability :
500PCS Per Month
Delivery Time :
30 work days
Packaging Details :
420*130*195cm
Description
Weichai 6M33D633E200 Diesel Generator Set
Our Weichai 6M33D633E200 Diesel Generator is a high-performance, heavy-duty generator set designed for reliable prime and standby power applications. Engineered with the renowned Weichai engine, this 520kW unit features a robust soundproof canopy, making it ideal for applications requiring low noise operation without compromising power and durability. Perfect for construction, industrial, commercial, and emergency backup use.
520 kw Generator diesel Power by WEICHAI Engine 6M33D633E200 Leroy Somer Alternator Generators 650 Kva Generador 520 kw Generator diesel Power by WEICHAI Engine 6M33D633E200 Leroy Somer Alternator Generators 650 Kva Generador
Power Specifications
ParameterPrime PowerStandby Power
Rated Power (kVA)650715
Power Rating (kW)520572
Frequency (Hz)50
Engine Model6M33D633E200
Engine Speed (RPM)1500
Phase3
PF0.8
Control SystemDigital
Rated Voltage (V)400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time≥ 8h @ 75% load
PRP Prime Power: Available for unlimited annual hours in variable load applications according to GB/T2820-97; includes 10% overload capability for 1 hour within 12 hours of operation.
ESP Standby Power: Applicable for supplying emergency power during utility power interruptions. No overload, utility parallel, or negotiated outage operation capability available.
Dimensions and Weight
ModelBWC715BWC715S
TypeOpenSilent
Length (L) mm38004300
Width (W) mm17401600
Height (H) mm27452250
Tank Capacity (L)11961196
Engine Specifications
Engine Model & Manufacturer6M33D633E200 (WEICHAI)
Emission Certification----
Number of Cylinders6
Cylinder ArrangementIn-line
CycleL-Type
AspirationTurbocharging and Intercooling
Bore x Stroke150 x 185 mm
Cubic Capacity19.6 L
Compression Ratio15.0:1
Prime Power / Speed575 kW / 1500 rpm
Standby Power / Speed639 kW / 1500 rpm
Governor TypeMechanical Pump
Cooling SystemForce Water Cooling Cycle
Transient Frequency Deviation-0.833333333
Total Lubrication System Capacity61 L
Coolant Capacity (Engine Only)43.93 L
Fuel Consumption @ 100% Load575 g/kWh @ 1500 rpm
Starter MotorDC 24V
Charge AlternatorDC 24V
Alternator Specifications
Alternator BrandBOBIG
Alternator ManufacturerFUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator ModelBW-354F
Alternator Rated Power520kW / 650kVA
Rated Voltage (V)230V / 400V
Rated Frequency50Hz
Connecting Type3 Phase and 4 Wire
Number of Bearings1
Protection GradeIP23
Altitude≤1000m
Exciter TypeBrushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation ClassH Class
Telephone Influence Factor (TIF)≤50
THF≤2%
Voltage Regulation, Steady State≤±1%
Transient State Voltage≤-15%~+20%
Control Panel - DSE 6120
Auto start and auto mains failure control module with alternator frequency & CAN speed sensing.
Key Benefits
  • Automatically transfers between mains (utility) and generator
  • Hours counter for accurate monitoring and maintenance
  • User-friendly set-up and button layout
  • Multiple parameters monitored & displayed simultaneously
  • Configurable for wide range of applications
  • PLC editor for user configurable functions
Key Features
  • 4-line back-lit LCD text display
  • Multiple display languages
  • Five-key menu navigation
  • LCD alarm indication
  • Customizable power-up text and screen images
  • DSENet® expansion compatibility
  • Data logging facility
  • Internal PLC editor
  • 3-phase generator sensing and protection
  • Generator current and power monitoring (kW, kvar, kVA, pf)
  • Real time clock
  • Engine run-time scheduler
  • IP65 rating (with optional gasket)
520 kw Generator diesel Power by WEICHAI Engine 6M33D633E200 Leroy Somer Alternator Generators 650 Kva Generador
Available Options
EngineAlternatorFuel SystemGenerating Set
  • Water Jacket Preheater
  • Oil Preheater
  • Oil manual pump
  • PMG excitation
  • Space heater
  • Winding temperature measuring
  • 12 / 24 hour base tank
  • Bunded fuel tank
  • External fuel tank
  • Automatic fuel feeding
  • Switch between external tank and base tank (three-way valve)
  • Deepsea, ComAp, Smartgen etc. controller
  • Trailer
  • Tools with the machine
520 kw Generator diesel Power by WEICHAI Engine 6M33D633E200 Leroy Somer Alternator Generators 650 Kva Generador 520 kw Generator diesel Power by WEICHAI Engine 6M33D633E200 Leroy Somer Alternator Generators 650 Kva Generador
