Specifications
Description
CTS Modular EV Battery Pack 460V 576V 614V 768V 100kWh 150kWh
For Electric Construction Vehicle, Tunnel Truck, and Mining Applications
Attribute Value
Battery type 614V LiFePO4 EV Battery Pack
Nominal Capacity 100Ah / 200Ah
Cell Grade A+ LiFePO4 Cell
Warranty 3 Years
Cycle life >3000 Cycles
PDU CTS Design PDU
CTS Battery Solutions for Electric Truck, Bus, Boat, Locomotive, Railway, and Subway
Using 153.6V 230Ah LiFePO4 Battery Modules
No. Module Qty Total Energy Rated Volt Rated Capacity Working Volt Discharge Power @ 25℃ Suggested Motor
1 3S 1P 105.9kWh 460.8V 230Ah 360V-525V 50kW rated, 100kW max, 200kW peak for 30 sec ≤100kW rated
Using 115.2V280Ah LiFePO4 Battery Modules
Using 115.2V304Ah LiFePO4 Battery Modules
Using 307.2V105Ah LiFePO4 Battery Modules
Why Choose This Standard EV Battery Module?
SOC Calculation
  • Real-time dynamic calibration
  • Vehicle operation conditions considered
  • Multi-method combination
  • High accuracy measurement of cell voltage/temperature/pack current
  • Extensive experimental data
Faults Diagnosis
  • Insulation & water leakage detection
  • Cell voltage range monitoring
  • High/low temperature alerts
  • Communication fault detection
  • Contactor weld monitoring
  • Power connection and temperature sensor fault detection
Electric vehicle lithium-ion battery - CTS battery
Electrical diagram of lithium battery system in standard box. Two-way high voltage input (double gun charging), two-way high voltage output (water cooling compressor output and motor driving output), and single-way low voltage output for communication with the whole vehicle.
