16 Inch Powerful Cutter Suction Dredger For Dredging
16 Inch Powerful Cutter Suction Dredger For Dredging
16 Inch Powerful Cutter Suction Dredger For Dredging
16 Inch Powerful Cutter Suction Dredger For Dredging
16 Inch Powerful Cutter Suction Dredger For Dredging
16 Inch Powerful Cutter Suction Dredger For Dredging
16 Inch Powerful Cutter Suction Dredger For Dredging
16 Inch Powerful Cutter Suction Dredger For Dredging
Specifications
Brand Name :
yongsheng
Model Number :
YSCSD400
Place of Origin :
shandong
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
50days
Packaging Details :
container
Diameter pipe :
400mm
Water flow :
2500-3000 m3/h
Solid capacity :
500 cbm/h
Main Engine :
746 kw Cummins engine
Max. dredging depth 45° :
14 m
Discharge distance :
1,400 m
Description

16 inch Powerful Cutter Suction Dredger for Dredging

product description

The cutter suction dredger is a highly efficient underwater excavation equipment. It utilizes a rotating

cutter head to loosen underwater sediments, while a powerful dredge pump transports the mixture

through pipelines to designated areas. This equipment is widely used in channel dredging, port

construction, land reclamation, and other marine engineering projects.


product parameters

YSCSD400 solid capacity 500 cbm/h hydraulic cutter suction dredger

Technical specifications

Water flow

2500-3000 m3/h

Solid capacity

500 cbm/h

Max. dredging depth 45°

14 m

Discharge distance

1,400 m

LOA

41 m

Dredger after assembly

41*6.8*1.8 m Length* width* depth

Dredger structure

Dismantle type and can be assembly in working site

Average draught

1.1 m

Diameter discharge pipe

400mm/16inch

Main Engine

746 kw Cummins engine

Rotate speed

1800 r/min

Auxiliary engine power

287 kw Cummins engine

Generator

16 kw

Hydraulic cutter power

120 kw

Total power

1,057 kw

16 Inch Powerful Cutter Suction Dredger For Dredging


16 Inch Powerful Cutter Suction Dredger For Dredging



Key Features

High Efficiency

Integrated cutting and pumping system ensures continuous operation with high productivity.

Precision Control

Equipped with GPS positioning and depth sensors for accurate excavation control.

Strong Adaptability

Suitable for various seabed materials, including silt, clay, sand, and even mildly rocky surfaces.

Cost-Effective & Eco-Friendly

Low energy consumption reduces operational costs; enclosed pipeline transport minimizes sediment

dispersion and water pollution.

Common Applications

  • Waterway Maintenance: Removing silt to ensure navigability

  • Port Expansion: Dredging basins and foundation trenches

  • Land Reclamation: Pumping sand for coastal development

  • Sand Mining: Extracting riverbed aggregates
