Customized River 12 Inch Dredge Pump For Sand
Customized River 12 Inch Dredge Pump For Sand
Customized River 12 Inch Dredge Pump For Sand
Customized River 12 Inch Dredge Pump For Sand
Customized River 12 Inch Dredge Pump For Sand
Customized River 12 Inch Dredge Pump For Sand
Customized River 12 Inch Dredge Pump For Sand
Customized River 12 Inch Dredge Pump For Sand
Specifications
Brand Name :
yongsheng
Model Number :
ys-12inch
Place of Origin :
china
MOQ :
1
Price :
75000usd/piece
Payment Terms :
T/T,L/C
Supply Ability :
100piece/Year
Delivery Time :
30 work days
Packaging Details :
Container
Customized :
customized
Condition :
new
Warranty :
1 year
Water Flow :
1400m3/h
Solid Capacity :
200-250 Cbm/H
Max.Dredging Depth 45° :
10m
Discharge Distance :
1000m
size :
20M*6.0M*1.5M
Main Engine :
456kw
consumption :
80L/H
Application :
sand suction
Work site :
river lake sea canal
Auxiliary engine power :
110kw
Core Components :
Engine, Pump
Description
High Quality Sand Dredger River Sand Pump Dredger With Cheap Price

1.Brief Introduction

Our jet suction sand dredger is equipped with high pressure pump. It washes sand up , then the sand pump

conveys the sand to the destination through the pipe. The dredger is novelly designed, easy to operate. It is

widely used for river dredging, lakes and ponds desilting , land reclaimation, ports cleaning and sand pumping.

Customized River 12 Inch Dredge Pump For Sand

Product Paramenters:
Model
Soild
capacity
Water flow
Dredging depth
Discharge distance
Main engine
Auxiliary engine
Total consumption
size(m)
6inch
40-50
m3/h
250
m3/h
6M
500M
120
KW
18L/H
10*3.8*1.6
8inch
80-100
m3/h
500
m3/h
8M
500M
176
KW
60KW
40L/H
14*4.5*1.2
10inch
150-180
m3/h
900
m3/h
10M
800M
294
KW
88KW
60L/H
17*5*1.2
12inch
200-250
m3/h
1400
m3/h
10M
1000M
456
KW
110KW
80L/H
20*6*1.5
14inch
300-400
m3/h
2000
m3/h
12M
1500M
735
KW
120KW
120L/H
24*6.6*1.6
16inch
400-500
m3/h
2600
m3/h
14M
1500M
882
KW
258KW
150L/H
24*7.2*1.8
18inch
500-600
m3/h
3000
m3/h
14M
1500M
1103
KW
456KW
220L/H
24*7.6*2.0
20inch
600-700
m3/h
3800
m3/h
14M
1500M
1250
KW
456KW
240L/H
26*7.6*2.0
Note: Because this equipment is a customized product, the maximum conveying distance of one pump is 1000-2000m. If long-distance conveying is required, a separate relay pump group is added.
The above output is calculated based on the conventional flow rate 15-20% concentration. If the long-distance conveying concentration will be reduced, it can be calculated based on about 15% of the flow rate.

Customized River 12 Inch Dredge Pump For Sand

Customized River 12 Inch Dredge Pump For Sand

Customized River 12 Inch Dredge Pump For Sand

Advantage:

1. Powerful power and excellent dredging capability: Our dredger suction dredgers are equipped with high-power engines, can work efficiently in various complex environments, have outstanding dredging capabilities, and are suitable for different engineering needs.
2. Efficient dredging and precise transportation: The equipment integrates advanced dredging and transportation technologies, which can quickly and accurately complete silt cleaning and transportation tasks, and improve engineering efficiency.
3. Customized services: We provide customized services, and carry out personalized design and modification of dredger suction dredgers according to the specific needs of customers to ensure that various special requirements are met.
4. Quality assurance: All exported hydraulic dredger suction dredgers undergo strict quality inspections to ensure first-class product quality, so that customers have no worries.
5. Thoughtful service: From pre-sales consultation to after-sales service, our professional team always provides customers with all-round support to ensure the smooth progress of the project.
