Chinese Made Hydraulic Aquatic Plant Harvester with High Cutting Capacity

product description

The innovative design features a sophisticated 3-section rod structure, meticulously crafted to enhance

efficiency. This design seamlessly integrates the front collection cabin, the spacious middle storage cabin,

and the rear storage and unloading cabin, ensuring streamlined operations.
Towering over the expansive middle storage cabin is an exceptional operation room, thoughtfully equipped

with an integrated operation table. This allows the captain to exercise complete control over the vessel,

making adjustments with precision and ease while remaining comfortably seated within the operation

room.

product parameters

RODUCTION PROCESS

Working principle:
1. During operation, the hydraulic system expertly maneuvers the hydraulic cylinder, gracefully lowering

the front collection cabin beneath the water's surface; subsequently, the bottom shear, placed at the

forefront of the cabin, is energized by the hydraulic motor. Its primary role is to sever the water grass

roots. Flanking each side of the collection cabin are two circular saw blades, rapidly rotating under the

hydraulic motor's influence, designed to slice through horizontally growing water grass with unmatched

precision.

2. The system's prowess extends beyond swiftly severing branches and vines, as it also clears a navigable

path for the cleaning boat. Following this, the two saw blades and bottom shears collaborate seamlessly

to execute the initial phase of cutting and collecting. The collection chain, strategically positioned in the

front cabin, activates and rotates, driven by the motor, effectively transporting the cut aquatic plants to

the storage cabin, completing the collection process with unmatched efficiency.

3. Once both the middle and rear cabins brim with water grass or floating debris, the cleaning boat is

navigated to the shoreline for unloading. During this process, the hydraulic system elevates the rear

unloading cabin, while the chain within the rear cabin accelerates, facilitating the swift unloading of

water grass or floating objects onto the shore.
This marks the completion of the initial cleaning cycle, following which the cleaning boat embarks on a

return journey to the site, prepared for additional cycles of efficient cleaning work.
This robust, fully automated cleaning vessel is designed for ultimate power and adaptability, equipped

to meet diverse operational needs. It boasts standard bottom shears and saw blades, with additional

optional components tailored to specific aquatic vegetation conditions, such as collection rakes, vertical

shears, crushing knives, mechanical swing arms, and wheel knives, ensuring comprehensive and versatile

cleaning solutions.

Core Functions and Objectives
Efficient Harvesting: Quickly cut, collect, and remove a variety of aquatic plants over a large area.

Overgrowth Control: Prevent aquatic weeds from becoming infested and blocking waterways, irrigation canals,

and hydropower station intakes, impacting navigation, water flow, and power generation.

Improving Water Quality: Removing large amounts of decaying or overgrown aquatic weeds reduces the

accumulation of nutrients (nitrogen and phosphorus) in the water, increases dissolved oxygen, and inhibits algae

blooms.

Restoring Ecological Balance: Controls invasive aquatic plants (such as water hyacinth and water peanut) and

protects native aquatic habitats.

Enhancing Landscape and Recreational Value: Clears weeds from scenic areas, park lakes, and urban rivers,

maintaining open and beautiful water surfaces for boating and water activities.

Ensuring Water Conservancy Facility Safety: Prevents aquatic weeds from clogging pump stations, gates,

pipelines, and other water conservancy facilities.

Aquaculture Management: Clears weeds from aquaculture waters to create a favorable growth environment for

fish, facilitating harvesting and management.

Main uses

River management: Remove aquatic plants that block the water, ensure flood and navigation safety
Landscape water maintenance: Suppress algae outbreaks and improve water transparency
Farm irrigation canals: Prevent aquatic plants from blocking pumps/pipes
Wetland protection: Control invasive species (such as water hyacinths)
Fishery management: Reduce oxygen consumption by rotten grass and avoid suffocation of fish

Advantages
High efficiency: hundreds of kilograms to tons of waterweed can be harvested per hour, far exceeding manual

efficiency
Automation: hydraulic control, single-person operation, reducing labor costs by 410.
Adaptability: adjustable cutting depth, suitable for different water environments

Company Profile

Shandong yongsheng dredging machinery Co.,LTD.is located in Huanglou Street, Qingzhou City,

Shandong Province, China. It has 2 production bases , total area near 2000m2, and more than 20

years manufacturing experience in water area environmental protective equipment. It is a professional

supplier of integrated with R&D, consultation, manufacturing and after-sale service. Yongsheng now

has obtained certification: ISO9001.

Summary:

Mowing boats are an indispensable professional tool for water ecological management and maintenance.

Through their efficient cutting, collection, dewatering, and unloading systems, they address the environmental,

economic, and safety issues associated with excessive aquatic weed growth. With the continuous advancement

of intelligent, renewable energy, and resource-based technologies, modern mowing boats are becoming more

efficient, environmentally friendly, and sustainable, providing strong technical support for protecting our "clear

waters and lush mountains."
