Advanced Ultrafine Grinder for Precision Fine Powder Manufacturing
Advanced Ultrafine Grinder for Precision Fine Powder Manufacturing
Specifications
Brand Name :
GNEZSCH
Certification :
CE ISO
Place of Origin :
China
MOQ :
One Set
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
50 sets per month
Delivery Time :
30-45 Workdays
Packaging Details :
Wooden case or container
Application :
Pharmaceutical, Chemical, Food
Grindingfineness :
0.045-0.2 mm
Voltage :
380/400V
Motorpower :
50KW
Dischargesize :
Adjustable
Grindingcapacity :
100-500 kg/h
Feedingsize :
≤10 mm
Automationlevel :
Semi-automatic
Productname :
Ultrafine Grinder
Noiselevel :
≤75 dB
Frequency :
50 Hz
Material :
Stainless Steel
Description

Advanced Ultrafine Grinder for Precision Fine Powder Manufacturing

Product Overview

The Advanced Ultrafine Grinder is engineered for industries that require highly refined powder with stable particle distribution and minimal contamination. Featuring a high-speed mechanical impact system combined with an intelligent airflow classifier, the grinder ensures consistent micron-grade output. The cooling airflow design significantly reduces heat buildup, making it ideal for heat-sensitive, fibrous, and moisture-prone materials used in pharmaceuticals, food processing, chemicals, and innovative materials.

Built for durability, performance, and precise powder control, this machine supports continuous operation in demanding production environments.

Key Features

  • Micron-Level Precision Output: Produces ultra-fine powders between 100 and 7000 mesh with exceptional uniformity.

  • Integrated Classifier System: Adjustable real-time fineness for versatile material processing.

  • Low-Temperature Grinding: Maintains bioactive compounds, color, aroma, and material integrity.

  • Wear-Resistant Construction: Optional hard alloy, ceramic liners, and stainless steel build for long service life.

  • Fully Sealed Dust-Free Operation: Negative-pressure system ensures clean working conditions and GMP compatibility.

  • High Efficiency: Optimized grinding chamber provides higher throughput while reducing energy consumption.

  • Quick Cleaning Structure: Tool-less opening makes maintenance simple and fast.

Technical Specifications

Parameter Value
Material SUS304 / SUS316L / Ceramic / Alloy Steel
Final Fineness 100–7000 mesh
Capacity 40–1600 kg/h
Max Feeding Size ≤ 8 mm
Motor Power 7.5–90 kW
Cooling System Air Cooling / Cryogenic Optional
Dust Removal Cyclone + Pulse Jet Collector
Voltage 220V / 380V / 415V / Customized
Compliance CE / ISO / GMP-Compatible

Applications

  • Herbal extracts, nutraceuticals, and botanical powders

  • Fine spices, seasonings, and food-grade micronized powders

  • Chemical materials, pigments, and advanced compounds

  • Pharmaceutical APIs and excipients

  • Mineral, ceramic, and new energy materials

  • Cosmetics, skincare, and ultrafine functional powders

Customer Benefits

  • Produces extremely fine, consistent powder for high-value applications

  • Protects active ingredients from temperature-related degradation

  • Reduces dust pollution and improves workshop cleanliness

  • Boosts productivity with continuous, stable operation

  • Highly flexible configuration suitable for various industries

  • Simplifies maintenance and reduces downtime

FAQ:

If you want to send inquriy to me about Stainless steel commercial Spice pulverizer machine,grinding pulverizer machine from China, could you please tell me?

  1. What material you want to grind, is it dry? what is the size of feed material ?
  2. What capacity you expect by spice grinding machine? (kg/h)
  3. What mesh or mm or micron(size) of the powder you want?
  4. What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...

    (We only provide 3P, because our machines are all for industrial use,not for family.)
  5. Usually we use stainless steel 304, if you want stainless steel 316, it's OK and please tell us.

Then our communication will be more efficient.
