Specifications
Model Number :
HF-B704-M
Machine Speed :
1200‑1400 rpm
MOQ :
1
Packaging Details :
Negotiable
Applicable Products :
Narrow elastic & non‑elastic webbings
Key Attributes :
Energy‑saving, high‑speed running, precise weft density control, automatic circulating lubrication, CE safety enclosure, supports multi‑strip weaving, suitable for mass & small‑batch orders
Price :
Negotiable
Voltage :
220V
Certification :
ISO9001/CE/UDEM
Operation Mode :
Touch‑screen digital control
Payment Terms :
T/T,L/C
Origin :
China
Place of Origin :
Dongguan,China
Core Components :
Servo motor, touch screen, planetary reducer, electrical control unit
Delivery Time :
15 work days
Drive Mode :
Servo motor drive with planetary reducer
Brand Name :
HUAFANG
Supply Ability :
300 sets/month
Machine Type :
High‑speed Servo Flat‑Head Shuttleless Ribbon Loom
Description

Production Overview

The HF‑B704‑M high‑speed servo flat head shuttleless ribbon loom is developed for production of various narrow elastic and non‑elastic webbings.
Built with reliable quality, our machines are certified with ISO9001, CE and UDEM. Equipped with computer smart touch screen and advanced servo motor control system, it realizes digital parameter adjustment instead of traditional mechanical setting.
This machine solves common production issues including unstable webbing quality, high energy consumption and heavy dependence on skilled operators. It supports multiple‑strip simultaneous weaving, fits both mass‑volume production and small‑batch diversified orders. It helps webbing factories improve finished‑product consistency, cut production cost and raise overall output efficiency.

Product Features

High‑Precision Weft Density Control

Adopts electronic servo motor and planetary reducer. It delivers accurate weft density control with flexible parameter adjustment. Suitable for complex‑pattern fabrics, improves product stability and fabric quality.

Energy‑Saving Servo Motor Control System

International advanced servo drive system brings high‑precision and fast response motion control. It runs at only 0.75KW under normal working status, saving 40% power consumption compared with traditional two‑speed motors. Strong adaptability under variable speed and variable load conditions.

Intuitive Computer Smart Display

All machine operations and weft‑density settings are completed via touch‑screen panel. Parameters modification and status monitoring are simple and efficient. It supports automatic linkage and data management for convenient production management.

Reliable & Safe Mechanical Structure

Comes with automatic circulating oil supply device for high‑speed gear and chain lubrication, extending spare‑part service life. Full‑covered carbon‑steel protective housing meets CE safety standards. Optimized floor‑standing integrated base enhances machine stability for higher running speed and capacity.

Wide Compatibility & Easy Maintenance

Core components are precisely manufactured with standardized interchangeable spare parts. Optional accessories are available to match different production demands. Suitable for medium‑large scale webbing manufacturers with various product requirements.

Application Areas

Underwear Webbing Production
Medical Bandage & Bra Strap Manufacturing
Elastic Tape & Sports Webbing Processing

Optional Accessories

Tape drawing machine
PT5 device
Double‑layer tape delivery device
Heavy‑duty knurled wheel assembly
Electronic servo active let‑off system with 1‑30 positions
Rear drop belt, take‑up and rewind device
HF‑C4012 heating setting machine

Packing & Delivery

Adopt standard export wooden case packaging, customized packaging solutions can be negotiated.

Company Profile

Huafang Machinery is a professional manufacturer specialized in narrow‑webbing textile machinery. We focus on the R&D, production and sales of various ribbon weaving equipment and supporting spare parts. Boasting abundant practical experience in the textile webbing industry, we keep optimizing machine performance to address actual production pain‑points for customers. We are committed to supplying stable‑quality, cost‑effective machinery and customized production solutions for webbing manufacturers all over the world.

Item HF6/66 HF12/27
Number of Webbing Strips 6 12
Reed Width 66 mm 27 mm
Number of Palm Frames 20 20
Paper Plate Cycle 48 48
Max. Power 4.3 KW 4.3 KW
Machine Speed 1200‑1400 rpm 1200‑1400 rpm
Weft Density 2.9‑40.3 2.9‑40.3
Paper‑Frame Length 530 mm 800 mm
Voltage 220V 220V
Machine Net Weight 600 KG 600 KG
Core components Servo motor, touch screen, planetary reducer, electrical control unit Servo motor, touch screen, planetary reducer, electrical control unit
Place of origin China China
Key Selling Points Multi‑strip weaving, energy‑saving servo drive, high‑speed operation, CE safety protection, digital touch‑screen control More weaving strips, energy‑saving servo drive, high‑speed operation, CE safety protection, digital touch‑screen control
