CR1325-4 Four Spindles CNC Router with Automatic 5 Side Machining High Precision Gear Rack Drive and 7.5KW Water Cooled Vacuum Pump
CR1325-4 Four Spindles CNC Router with Automatic 5 Side Machining High Precision Gear Rack Drive and 7.5KW Water Cooled Vacuum Pump
Specifications
Model Number :
CR1325-12T
Certification :
CE ,ISO
MOQ :
1SET
Payment Terms :
T/T
Delivery Time :
25WORKDAYS
Brand Name :
CRESTAL
Supply Ability :
100SETS/MONTH
Place of Origin :
QINGDAO
Description
CR-6L Four Spindles CNC Router
Product Overview
The CR-6L four spindles CNC router is designed for cabinet connections suitable for ordinary three-in-one, buckle, slot slip, and lamino stealth applications. Features include special-shaped plate processing, automatic punching, grooving, material opening, one-button vacuuming for material pushing, and integrated software for automatic disassembly and optimized typesetting to reduce waste.
Applications
  • Panel furniture
  • Customized furniture
  • Cabinets and wardrobes
  • Office furniture
  • Solid wood furniture
  • Tables, chairs, doors, windows
  • Wood products
  • Decoration industry
Processable Materials
  • Density board
  • Ecological board
  • Multi-layer board
  • Particleboard
  • Flat solid board
  • Aluminum honeycomb board
  • Other plates
Performance Data
Category Material Type Quantity
Daily working amount Chipboard 45-95 pcs
MDF 80-150 pcs
Solid wood 60-110 pcs
Knife working ability Chipboard 8-20 pcs
MDF 50-70 pcs
Solid wood 20-35 pcs
Technical Specifications
Voltage 380V±5% 50HZ1±1%
Rack BECHARM
Subregion Vacuum Table 6 subregion
Reducer Zhuo LAN high precision reducer
Dimension 4000×2300×2500mm
Z Axis Parts Xin Jie 1500w pure servo motor with holding lock
Drive Parts X, Y high precision gear rack drive Z shaft screw, Y shaft guide rail, with flange slider
Motor Group Xin Jie 1500w servo
Vacuum Power 7.5kw Water cooled high power vacuum pump
Machine Structure Heavy duty with six leg, high temperature quenching
Machine Processing Method Automatic 5 side machining with accuracy 0.002mm
Frequency Converter Best
Main Spindle Power 9KW spindle 9KW, 24000r/min
Working Table Structure High quality thickened ABS with brownish red color
Z Axis Fixed Method Adopt integrated motor screw rod bearing C & U
Rail Guide and Rack Installation Error Less than 0.05mm
Cable High flexible double protection full shield cable
Appearance Industrial design appearance, beautiful and generous surrounding
Software Support G code / Code: (NC), MMG, PLT, Eng, DXF dismantling software or door panel software
Machine Cabinet Independent large cabinet with four fans circulating cooling mode
Working Speed Limit speed can reach 80 m/min
Control System Taiwai LNC(MW2200A) Handwheel
Position System Right angle panel position system
Working Size 1220×2800mm (Customized size available)
Unloading Function Double air automatic pushing (with secondary dust collection)
Auxiliary Function Side emergency stop button, positioning cylinder and dust collector
Electrical Components SIEMENSS
Dust Collector Method Spindle automatic partition dust collector
Warranty Period 1 Year with export quality standards
