C300 Combination Machine with 300*1500 mm Working Table, 5700 r. p. m Cutter Block Rotation Speed, and 3.0 HP Motor for Precision Woodworking
C300 Combination Machine with 300*1500 mm Working Table, 5700 r. p. m Cutter Block Rotation Speed, and 3.0 HP Motor for Precision Woodworking
Specifications
Description
C300 Combination Woodworking Machine
The C300 serves as the ideal bridge between hobbyist equipment and professional-grade machinery. Designed for the demanding wood craftsman who refuses to compromise on safety, precision, and reliability, this machine provides the perfect toolset to bring your woodworking creations to life.
Technical Specifications
Planer Unit
Parameter Specification
Working Table 300 × 1500 mm
Cutter Block Diameter 70 mm
Cutter Block Rotation Speed 5700 rpm
Dimension Knives (3 knives) 300 × 20 × 3 mm
Maximum Table Adjustment 4 mm
Thicknesser Unit
Parameter Specification
Working Table 300 × 660 mm
Feeding Speed 7 m/min
Working Height 4-220 mm
Cutter Block Rotation Speed 5700 rpm
Maximum Cutting Depth 4 mm
Mortiser Unit
Parameter Specification
Working Table 250 × 500 mm
Longitudinal/Transversal/Vertical Stroke 205/95/90 mm
Chuck (M18×1.5-S) 0-16 mm
Chuck Rotation Speed 5700 rpm
Circular Saw Unit
Parameter Specification
Working Table 220 × 1000 mm
Shaft Rotation Speed 4500 rpm
Blade Diameter 250 mm
Blade Bore Diameter 30 mm
Cutting Height 90° 80 mm
Maximum Distance Between Blade and Fence 500 mm
Blade Inclination 45°
Maximum Cutting Height 45° 50 mm
Shaft Rotation Speed Engraver 7000 rpm
Engraver Blade Diameter 90 mm
Engraver Blade Bore Diameter 22 mm
Spindle Moulder Unit
Parameter Specification
Working Tables 220 × 1000 mm
Shaft Rotation Speeds 2000/3100/4400/7000 rpm
Standard Shaft Diameter 30 mm
Spindle Length 105 mm
Shaft Vertical Stroke 115 mm
Maximum Tool Diameter 160 mm
Maximum Tenoning Depth 55 mm
General Specifications
Parameter Specification
3-Phase Motor 3.0 HP / 2.2 KW
Weight 550 kg
