12 W / 18W Pure White square LED Panel Light 225mm x 225mm , Flat Led panels
12 W / 18W Pure White square LED Panel Light 225mm x 225mm , Flat Led panels
12 W / 18W Pure White square LED Panel Light 225mm x 225mm , Flat Led panels
12 W / 18W Pure White square LED Panel Light 225mm x 225mm , Flat Led panels
Specifications
Place of Origin :
China
Brand Name :
FUSION
Certification :
CE,ROHS
MOQ :
negotiation
Price :
negotiation
Packaging Details :
caton
Delivery Time :
5-10 days
Payment Terms :
T/T, paypal, western-union
Supply Ability :
10000PCS/month
Description

12 W 18W Pure White square LED Panel Light 225mm x 225mm , Flat Led panels

Detailed Product Description

18 W Pure White LED Flat Panel Light 5000K Aluminum For Supermarket

18 Wattage Beam Angle 120° LED Flat Panel Light For Supermarket

Description:

1. Environmental friendly with no mercury content

2. LED as light source offer very long life as compared to conventional source

3. Easy installation

4. Compact design, less weight and high cost performance

Quick Detail:

1. Operating Temperature: (-20~50℃)

2. Frequency: 50/60Hz

3. Power Supply Efficiency: 88%

4. PFC: 0.95

Specifications :

PARAMETER

· Item NO:

FSFP18W W/NW/WW

· Dimension:

225mm x 225mm/Cut hole 200mm x 200mm

· LED type:

SMD 2835

· LED Q'ty:

90pcs

· Material:

Aluminum

· Working temperature:

-20.C~50.C

· Installation method:

Embedded.

· IP rate

IP40

· N.W.(±0.1Kg)

0.85Kg

PHOTOELECTRICITY PARAMETER

· CCT :

2900-6500K

· Light Efficiency(±10%):

100lm / Watt

· Flux.(±10%):

1800lm

· Input voltage:

AC 86-265V

· Input Power:

18W

· CRI:

Ra>80

· Dimmable:

Non Dimmable

· Lighting Angle:

120°

DIMENSIONAL DRAWING

Applications:



◎ Commercial lighting, environmentally friendly lighting, warehouse , supermarket and home illumination.
◎ IT, call centers, shopping malls and Exhibition Hall, art gallery, the hospital hotel and other public places.
◎ Exhibition Hall, art galleries, museums, offices, reading-room, corridor, staircase lighting,such as contour rang

Installation instrustions




Why choose us?

  1. Every down light will pass 18 tests (including led chip light output test, voltage test, power supplier test, light shell test,and so on) before we delivery.
  2. We use top range material for led down light, for example, led chip from taiwan, the die casting shell , and very stable power supplier.
  3. Fast lead time
  4. Fast response
  5. Wow price

thanks for your inquiry, we will response you in 8 hours.
