Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Specifications
Brand Name :
Bright Pack
Model Number :
B010
Certification :
patent for invention、BRC、GRS
Place of Origin :
Guangdong,China
MOQ :
100pcs
Price :
￥0.02-0.11/pcs
Payment Terms :
T/T,Western Union
Supply Ability :
200000pcs/day
Delivery Time :
11-13work days
Packaging Details :
Export special carton packaging and plate
Customization :
Support
Colour :
Up To 10 Colour Or No Printed
Odor Proof :
Yes
Custom Order :
YES.
Colors :
CMYK/Pantone
Sample :
Free
Puncture Resistant :
Yes
Packaging Type :
Bulk Pack
Quantity Per Pack :
100
Recyclable :
Yes
Quantity :
Pack of 100 bags
Bag Type :
Three side seal stand up bag
Bpa Free :
Yes
Color :
Transparent
Height :
115 MM
Description
Vacuum Sealable AL PE Composite Pouch Puncture Resistant
Product Attributes
Attribute Specification
Material Composition 3-layer structure: Aluminum foil (AL) barrier (6-12µm) + Polyethylene (PE) sealing layer (50-100µm), laminated with optional PET outer layer for enhanced durability
Barrier Performance
  • Oxygen transmission rate (OTR): ≤0.5 cm³/m²*day*atm
  • Water vapor transmission rate (WVTR): ≤0.1 g/m²*day
Sealing & Durability
  • Heat-seal strength: ≥4.5 N/15mm (150°C, 0.3MPa pressure)
  • Puncture resistance: ≥8 kgf/mm² (ASTM D2582)
Temperature Resistance
  • Operating range: -20°C to 120°C
  • Retort-safe (withstands 121°C sterilization for 30 mins)
Surface Properties
  • Anti-static treatment (optional)
  • Matte/glossy finish options for print compatibility
Certifications FDA 21 CFR 177.1520 (food contact), RoHS, REACH, ISO 9001
Applications Vacuum-sealed food storage (e.g., freeze-dried goods), pharmaceutical packaging, industrial parts protection
Sustainability
  • Recyclable PE layer (up to 30% post-industrial recycled content)
  • Low-VOC adhesives
Product Specifications
Parameter Details
Thickness Range 0.1-0.3mm (total composite thickness, customizable)
Pouch Dimensions
  • Standard sizes: 6"x10" (pint) to 12"x18" (gallon)
  • Custom widths: 100-1,200mm
Seal Type Heat-sealed edges + optional resealable zipper/spout closures
Print Compatibility Flexographic/gravure printing (up to 8 colors) with Pantone matching and 1200 DPI resolution
Packaging Vacuum-sealed rolls in moisture-proof OPP sleeves + reinforced cartons (FBA-ready)
MOQ 100 pieces
Lead Time 10-15 days (samples); 25-35 days (bulk orders)
