Specifications
Brand Name :
Bright Pack
Model Number :
B010
Certification :
patent for invention、BRC、GRS
Place of Origin :
Guangdong,China
MOQ :
100pcs
Price :
￥0.02-0.11/pcs
Payment Terms :
T/T,Western Union
Supply Ability :
200000pcs/day
Delivery Time :
11-13work days
Packaging Details :
Export special carton packaging and plate
Customization :
Support
Colour :
Up To 10 Colour Or No Printed
Odor Proof :
Yes
Custom Order :
YES.
Colors :
CMYK/Pantone
Sample :
Free
Puncture Resistant :
Yes
Packaging Type :
Bulk Pack
Quantity Per Pack :
100
Recyclable :
Yes
Quantity :
Pack of 100 bags
Bag Type :
Three side seal stand up bag
Bpa Free :
Yes
Color :
Transparent
Height :
115 MM
Description
Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength
Product Attributes & Specifications
Attribute Specifications Reference
Material Composition Multi-layer composite: Aluminum foil (45-60µm) laminated with heat-resistant PE (polyethylene) layer. Optional PET outer layer for enhanced durability. 1 2
Heat Resistance Stable performance under retort sterilization (121°C for 30 mins) and continuous use up to 150°C. Suitable for autoclave processes. 6 9
Seal Strength ≥35N/15mm (tested per QB/T 2358-98 standard). Achieved via co-extrusion of high-performance PE layers and optimized heat-sealing parameters. 2 9
Barrier Properties - Oxygen Transmission Rate (OTR): ≤0.05 cc/m²*day (25°C, 0% RH)
- Water Vapor Transmission Rate (WVTR): ≤0.5 g/m²*day (38°C, 90% RH)		 1 5
Thickness 135-200 microns (adjustable based on application). Aluminum layer: 45-60µm; PE layer: 70-100µm. 1 9
Width & Roll Length - Standard width: 200-1,200mm
- Roll length: 500-5,000 meters (core diameter: 76mm or 152mm)		 3 7
Printing & Surface Finish High-definition rotogravure printing (up to 8 colors). Optional matte/gloss lamination or anti-static coating. 1 5
Certifications FDA 21 CFR 177.1520 (food contact), ISO9001, REACH, RoHS, and BRC for food safety. 3 4
Applications Retortable pouches for ready-to-eat meals, pet food, liquid soups, and pharmaceutical blister packaging. 1 9
Sustainability Recyclable PE layer. Aluminum foil compatible with industrial recycling streams. Reduced carbon footprint vs. rigid packaging. 8 9
MOQ 20,000-50,000 linear meters (negotiable for custom designs) 1 3
Lead Time 25-35 days (expedited options available for bulk orders)
Product Gallery
​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength ​Retortable AL/PE Foil Packaging Roll | 150℃ Heat Resistance & 35N/15mm Seal Strength
Key Advantages
  • Exceptional heat resistance for retort sterilization processes
  • High seal strength ensures package integrity
  • Superior barrier properties for extended product shelf life
  • Customizable dimensions and printing options
  • Compliant with international food safety standards
  • Environmentally responsible material composition
